D-Sub, D-Shaped Connectors(4212)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Operating Temperature | Mounting Type | Features | Color | Termination | Ingress Protection | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | REACH Status | ECCN | HTSUS | Standard Package | Connector Type | Number of Rows | Contact Finish | Contact Finish Thickness | Current Rating (Amps) | Contact Material | Material Flammability Rating | Contact Type | Number of Positions | Voltage Rating | Flange Feature | Dielectric Material | Shell Material, Finish | Connector Style | Wire Gauge | Contact Form | Shell Size, Connector Layout | Backset Spacing |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
09563615713 | 11.1500 |  |
1 | 0.00000000 | HARTING | - | Tray | Active | -40°C ~ 85°C | Through Hole | Board Lock, Grounding Indents | - | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 100 | Plug, Male Pins | 3 | Gold or Gold-Palladium | 30.0µin (0.76µm) | 2A | Copper Alloy | UL94 V-0 | Signal | 44 | - | Mating Side, Female Screwlock (4-40) | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Steel, Nickel Plated | D-Sub, High Density | - | Stamped | 3 (DB, B) High Density | - | |
 |
09564005615050 | 13.6900 | |
3724 | 0.00000000 | HARTING | - | Bulk | Active | -40°C ~ 85°C | Free Hanging (In-Line) | Grounding Indents | Black | Solder Cup | - | - | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 3 | Gold | 30.0µin (0.76µm) | 2A | Copper Alloy | UL94 V-0 | Signal | 62 | - | Housing/Shell (Unthreaded) | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Steel, Tin Plated | D-Sub, High Density | 24 AWG | Stamped | 4 (DC, C) High Density | - | |
 |
09564517512 | 14.0900 | |
5 | 0.00000000 | HARTING | - | Tray | Active | -40°C ~ 85°C | Through Hole | Board Lock | - | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | Receptacle, Female Sockets | 3 | - | - | 2A | Copper Alloy | UL94 V-0 | Signal | 62 | - | Board Side (4-40) | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Steel, Nickel Plated | D-Sub, High Density | - | Stamped | 4 (DC, C) High Density | - | |
 |
09564615712 | 14.7100 | |
44 | 0.00000000 | HARTING | - | Bulk | Active | -40°C ~ 85°C | Through Hole | Board Lock, Grounding Indents | - | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 3 | Gold or Gold-Palladium | 30.0µin (0.76µm) | 2A | Copper Alloy | UL94 V-0 | Signal | 62 | - | Board Side (4-40) | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Steel, Nickel Plated | D-Sub, High Density | - | Stamped | 4 (DC, C) High Density | - | |
 |
09564625812 | 19.3900 | |
4656 | 0.00000000 | HARTING | - | Bulk | Active | -40°C ~ 85°C | Through Hole, Right Angle | Board Lock, Grounding Indents | - | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 3 | Gold or Gold-Palladium | 30.0µin (0.76µm) | 2A | Copper Alloy | UL94 V-0 | Signal | 62 | - | Housing/Shell (4-40) | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Steel, Nickel Plated | D-Sub, High Density | - | Stamped | 4 (DC, C) High Density | 0.350" (8.89mm) | |
 |
09565004715050 | 19.9600 | |
33 | 0.00000000 | HARTING | - | Bulk | Active | -40°C ~ 85°C | Free Hanging (In-Line) | - | Black | Solder Cup | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 50 | Receptacle, Female Sockets | 4 | Gold | 30.0µin (0.76µm) | 2A | Copper Alloy | UL94 V-0 | Signal | 78 | - | Housing/Shell (Unthreaded) | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Steel, Tin Plated | D-Sub, High Density | 24 AWG | Stamped | 5 (DD, D) High Density | - | |
|
09565005615050 | 17.4800 | |
7869 | 0.00000000 | HARTING | - | Bulk | Active | -40°C ~ 85°C | Free Hanging (In-Line) | Grounding Indents | Black | Solder Cup | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 50 | Plug, Male Pins | 4 | Gold | 30.0µin (0.76µm) | 2A | Copper Alloy | UL94 V-0 | Signal | 78 | - | Housing/Shell (Unthreaded) | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Steel, Tin Plated | D-Sub, High Density | 24 AWG | Stamped | 5 (DD, D) High Density | - | |
 |
09565515512 | 17.1498 | |
9418 | 0.00000000 | HARTING | - | Bulk | Active | -40°C ~ 85°C | Through Hole | Board Lock | - | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | Receptacle, Female Sockets | 4 | Gold or Gold-Palladium | 30.0µin (0.76µm) | 2A | Copper Alloy | UL94 V-0 | Signal | 78 | - | Board Side (4-40) | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Steel, Nickel Plated | D-Sub, High Density | - | Stamped | 5 (DD, D) High Density | - | |
 |
09565525612 | 26.3600 | |
9 | 0.00000000 | HARTING | - | Bulk | Active | -40°C ~ 85°C | Through Hole, Right Angle | Board Lock | - | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | Receptacle, Female Sockets | 4 | Gold or Gold-Palladium | 30.0µin (0.76µm) | 2A | Copper Alloy | UL94 V-0 | Signal | 78 | - | Housing/Shell (4-40) | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Steel, Nickel Plated | D-Sub, High Density | - | Stamped | 5 (DD, D) High Density | 0.350" (8.89mm) | |
 |
09565527612 | 22.6800 | |
99 | 0.00000000 | HARTING | - | Bulk | Active | -40°C ~ 85°C | Through Hole, Right Angle | Board Lock | - | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | Receptacle, Female Sockets | 4 | - | - | 2A | Copper Alloy | UL94 V-0 | Signal | 78 | - | Housing/Shell (4-40) | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Steel, Nickel Plated | D-Sub, High Density | - | Stamped | 5 (DD, D) High Density | 0.350" (8.89mm) | |
 |
09565615700 | 18.2000 | |
7 | 0.00000000 | HARTING | - | Bulk | Active | -40°C ~ 85°C | Through Hole | Grounding Indents | - | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 4 | Gold or Gold-Palladium | 30.0µin (0.76µm) | 2A | Copper Alloy | UL94 V-0 | Signal | 78 | - | Housing/Shell (Unthreaded) | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Steel, Nickel Plated | D-Sub, High Density | - | Stamped | 5 (DD, D) High Density | - | |
 |
09565615712 | 20.9828 | |
9600 | 0.00000000 | HARTING | - | Bulk | Active | -40°C ~ 85°C | Through Hole | Board Lock, Grounding Indents | - | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 4 | Gold or Gold-Palladium | 30.0µin (0.76µm) | 2A | Copper Alloy | UL94 V-0 | Signal | 78 | - | Board Side (4-40) | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Steel, Nickel Plated | D-Sub, High Density | - | Stamped | 5 (DD, D) High Density | - | |
 |
09565615713 | 19.5100 | |
3 | 0.00000000 | HARTING | - | Bulk | Active | -40°C ~ 85°C | Through Hole | Board Lock, Grounding Indents | - | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 4 | Gold or Gold-Palladium | 30.0µin (0.76µm) | 2A | Copper Alloy | UL94 V-0 | Signal | 78 | - | Mating Side, Female Screwlock (4-40) | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Steel, Nickel Plated | D-Sub, High Density | - | Stamped | 5 (DD, D) High Density | - | |
 |
09641117218 | - | |
2842 | 0.00000000 | HARTING | - | Bulk | Obsolete | -55°C ~ 125°C | Free Hanging (In-Line) | Filter | Natural | Solder Cup | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 100 | Receptacle, Female Sockets | 2 | - | - | 7.5A | Copper Alloy | UL94 V-0 | Signal | 9 | 100V | Cable Side (M3) | Polycyclohexylenedimethylene Terephthalate (PCT) | Steel | D-Sub | 20 AWG | Machined | 1 (DE, E) | - | |
 |
09641127220 | - | |
9458 | 0.00000000 | HARTING | - | Bulk | Obsolete | -20°C ~ 125°C | Through Hole | Filter | Natural | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 25 | Receptacle, Female Sockets | 2 | - | - | 7.5A | Copper Alloy | UL94 V-0 | Signal | 9 | 100V | Housing/Shell (Unthreaded) | Polycyclohexylenedimethylene Terephthalate (PCT) | Steel, Tin Plated | D-Sub | - | Machined | 1 (DE, E) | - | |
 |
09641127230 | 25.6000 | |
2530 | 0.00000000 | HARTING | - | Bulk | Active | -20°C ~ 125°C | Through Hole | Filter | Natural | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 25 | Receptacle, Female Sockets | 2 | - | - | 7.5A | Copper Alloy | UL94 V-0 | Signal | 9 | 100V | Housing/Shell (Unthreaded) | Polycyclohexylenedimethylene Terephthalate (PCT) | Steel | D-Sub | - | Machined | 1 (DE, E) | - | |
 |
09641147228 | - | |
3246 | 0.00000000 | HARTING | - | Bulk | Obsolete | -55°C ~ 125°C | Through Hole, Right Angle | Filter, Mounting Brackets | Natural | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 25 | Receptacle, Female Sockets | 2 | - | - | 7.5A | Copper Alloy | UL94 V-0 | Signal | 9 | 100V | Mating Side, Female Screwlock (4-40) | Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled | Steel, Tin Plated | D-Sub | - | Machined | 1 (DE, E) | 0.401" (10.20mm) | |
 |
09641147235 | - | |
5950 | 0.00000000 | HARTING | - | Bulk | Obsolete | -20°C ~ 125°C | Through Hole, Right Angle | Board Lock, Filter, Mounting Brackets | Natural | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | Receptacle, Female Sockets | 2 | - | - | 7.5A | Copper Alloy | UL94 V-0 | Signal | 9 | 100V | Mating Side, Female Screwlock (M3) | Polycyclohexylenedimethylene Terephthalate (PCT) | Steel, Tin Plated | D-Sub | - | Machined | 1 (DE, E) | 0.401" (10.20mm) | |
 |
09641147240 | - | |
2319 | 0.00000000 | HARTING | - | Bulk | Obsolete | -55°C ~ 125°C | Through Hole, Right Angle | Filter | Natural | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 25 | Receptacle, Female Sockets | 2 | - | - | 7.5A | Copper Alloy | UL94 V-0 | Signal | 9 | 100V | Housing/Shell (Unthreaded) | Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled | Steel, Tin Plated | D-Sub | - | Machined | 1 (DE, E) | 0.401" (10.20mm) | |
|
09641149066 | - | |
1164 | 0.00000000 | HARTING | - | - | Obsolete | - | - | - | - | - | - | - | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | - | 2 | - | - | - | - | - | Signal | 9 | - | - | - | - | D-Sub | - | - | 1 (DE, E) | - | |
 |
09641227218 | - | |
5974 | 0.00000000 | HARTING | - | Bulk | Obsolete | -55°C ~ 125°C | Through Hole | Filter, Grounding Indents | Natural | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 25 | Plug, Male Pins | 2 | - | - | 7.5A | Copper Alloy | UL94 V-0 | Signal | 9 | 100V | Board Side (M3) | Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled | Steel, Tin Plated | D-Sub | - | - | 1 (DE, E) | - | |
 |
09641247218 | - | |
5018 | 0.00000000 | HARTING | - | Bulk | Obsolete | -55°C ~ 125°C | Through Hole, Right Angle | Filter, Grounding Indents, Mounting Brackets | Natural | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 25 | Plug, Male Pins | 2 | - | - | 7.5A | Copper Alloy | UL94 V-0 | Signal | 9 | 100V | Mating Side, Female Screwlock (4-40) | Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled | Steel, Tin Plated | D-Sub | - | - | 1 (DE, E) | - | |
 |
09641247236 | - | |
8755 | 0.00000000 | HARTING | - | Bulk | Obsolete | -55°C ~ 125°C | Through Hole, Right Angle | Filter, Grounding Indents, Mounting Brackets | Natural | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 25 | Plug, Male Pins | 2 | - | - | 7.5A | - | UL94 V-0 | Signal | 9 | 100V | Housing/Shell (4-40) | Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled | Steel, Tin Plated | D-Sub | - | - | 1 (DE, E) | - | |
|
09641247237 | - | |
8219 | 0.00000000 | HARTING | - | Bulk | Obsolete | -55°C ~ 125°C | Through Hole, Right Angle | Filter, Grounding Indents, Mounting Brackets | Natural | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 25 | Plug, Male Pins | 2 | - | - | 7.5A | - | UL94 V-0 | Signal | 9 | 100V | Housing/Shell (M3) | Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled | Steel, Tin Plated | D-Sub | - | - | 1 (DE, E) | - | |
|
09641249039 | - | |
6747 | 0.00000000 | HARTING | - | - | Obsolete | - | - | - | - | - | - | - | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 25 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
09642117237 | 33.5810 | |
1344 | 0.00000000 | HARTING | - | Bulk | Active | -55°C ~ 125°C | Free Hanging (In-Line) | Filter | Natural | Solder Cup | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 100 | Receptacle, Female Sockets | 2 | - | - | 7.5A | Copper Alloy | UL94 V-0 | Signal | 15 | 100V | Cable Side (4-40) | Polycyclohexylenedimethylene Terephthalate (PCT) | Steel, Tin Plated | D-Sub | 20 AWG | Machined | 2 (DA, A) | - | |
 |
09642127210 | 28.4000 | |
25 | 0.00000000 | HARTING | - | Bulk | Active | -20°C ~ 125°C | Through Hole | Filter | Natural | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 25 | Receptacle, Female Sockets | 2 | - | - | 7.5A | Copper Alloy | UL94 V-0 | Signal | 15 | 100V | Housing/Shell (Unthreaded) | Polycyclohexylenedimethylene Terephthalate (PCT) | Steel | D-Sub | - | Machined | 2 (DA, A) | - | |
|
09642147230 | - | |
7811 | 0.00000000 | HARTING | - | Bulk | Obsolete | -55°C ~ 125°C | Through Hole, Right Angle | Filter | Natural | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 25 | Receptacle, Female Sockets | 2 | - | - | 7.5A | Copper Alloy | UL94 V-0 | Signal | 15 | 100V | Housing/Shell (Unthreaded) | Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled | Steel, Tin Plated | D-Sub | - | Machined | 2 (DA, A) | 0.401" (10.20mm) | |
 |
09642217237 | 32.2922 | |
3236 | 0.00000000 | HARTING | - | Bulk | Active | -55°C ~ 125°C | Free Hanging (In-Line) | Filter, Grounding Indents | Natural | Solder Cup | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 100 | Plug, Male Pins | 2 | - | - | 7.5A | Copper Alloy | UL94 V-0 | Signal | 15 | 100V | Cable Side (4-40) | Polycyclohexylenedimethylene Terephthalate (PCT) | Steel, Tin Plated | D-Sub | 20 AWG | Machined | 2 (DA, A) | - | |
 |
09642227210 | 34.6200 | |
51 | 0.00000000 | HARTING | - | Bulk | Active | -20°C ~ 125°C | Through Hole | Filter, Grounding Indents | Natural | Solder | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 25 | Plug, Male Pins | 2 | - | - | 7.5A | Copper Alloy | UL94 V-0 | Signal | 15 | 100V | Housing/Shell (Unthreaded) | Polycyclohexylenedimethylene Terephthalate (PCT) | Steel | D-Sub | - | Machined | 2 (DA, A) | - |
