D-Sub, D-Shaped Connectors(166763)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Operating Temperature | Mounting Type | Features | Base Product Number | Color | Termination | Ingress Protection | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | REACH Status | ECCN | HTSUS | Standard Package | Connector Type | Number of Rows | Contact Finish | Contact Finish Thickness | Current Rating (Amps) | Contact Material | Material Flammability Rating | Contact Type | Number of Positions | Voltage Rating | Flange Feature | Dielectric Material | Shell Material, Finish | Connector Style | Wire Gauge | Contact Form | Shell Size, Connector Layout | Backset Spacing |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
DBL5W5S543M40LF | - |  |
9492 | 0.00000000 | Amphenol ICC (FCI) | DW | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | Mounting Brackets | DBL5W5S543 | - | Solder | - | download | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 80 | Receptacle, Female Sockets | 1 | Gold | - | 40A | Brass | UL94 V-0 | Power | 5 (Power) | 300V | Housing/Shell (M3) | Thermoplastic | Steel, Nickel Plated | D-Sub, Combo | - | - | 3 (DB, B) - 5W5 | - | |
|
DBL9W4S300G30LF | - | |
7091 | 0.00000000 | Amphenol ICC (FCI) | DW | Tray | Active | -55°C ~ 125°C | Through Hole | Board Lock | DBL9W4S300 | - | Solder | - | download | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 80 | Receptacle, Female Sockets | 2 | Gold | - | 7.5A, 30A | Brass | UL94 V-0 | Signal and Power | 9 (5 + 4 Power) | 300V | Board Side (M3) | Thermoplastic | Steel, Nickel Plated | D-Sub, Combo | - | - | 3 (DB, B) - 9W4 | - | |
|
DBM13W3P500CN | 7.3848 | |
5685 | 0.00000000 | Amphenol ICC (FCI) | DMW HE507 | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | - | DBM13W3 | - | Solder | - | download | RoHS non-compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 40 | Plug, Male Pins | 2 | Gold | - | 7.5A per Contact | Brass | UL94 V-0 | Signal and Power (Not Included) | 13 (10 + 3 Power) | 300V | Housing/Shell (Unthreaded) | Thermoplastic | Steel, Yellow Cadmium Plated | D-Sub, Combo | - | - | 3 (DB, B) - 13C3, 13W3 | 0.406" (10.30mm) | |
|
DBM13W3P500MN | 9.3381 | |
3398 | 0.00000000 | Amphenol ICC (FCI) | DMW HE507 | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | Mounting Brackets | DBM13W3 | - | Solder | - | download | RoHS non-compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 20 | Plug, Male Pins | 2 | Gold | - | 7.5A | Brass | UL94 V-0 | Signal and Power (Not Included) | 13 (10 + 3 Power) | 300V | Housing/Shell (Unthreaded) | Thermoplastic | Steel, Yellow Cadmium Plated | D-Sub, Combo | - | - | 3 (DB, B) - 13C3, 13W3 | 0.406" (10.30mm) | ||
 |
DBM17W2PN | 14.5600 | |
178 | 0.00000000 | Amphenol ICC (FCI) | DMW HE507 | Tray | Active | -55°C ~ 125°C | Free Hanging (In-Line) | - | DBM17W2 | - | Solder Cup | - | download | RoHS non-compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 20 | Plug, Male Pins | 2 | Gold | - | 7.5A per Contact | Phosphor Bronze | UL94 V-0 | Signal and Power (Not Included) | 17 (15 + 2 Power) | 300V | Housing/Shell (Unthreaded) | Thermoplastic | Steel, Yellow Cadmium Plated | D-Sub, Combo | - | - | 3 (DB, B) - 17W2 | - | |
|
DBM25S500CN | - | |
6482 | 0.00000000 | Amphenol ICC (FCI) | DM HE508 | Tray | Obsolete | -55°C ~ 155°C | Through Hole, Right Angle | - | DBM25S5 | - | Solder | - | download | RoHS non-compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 20 | Receptacle, Female Sockets | 2 | Gold | - | 7.5A per Contact | Brass | UL94 V-0 | Signal | 25 | 300V | Housing/Shell (Unthreaded) | Thermoplastic | Steel, Yellow Cadmium Plated | D-Sub | - | Machined | 3 (DB, B) | 0.406" (10.30mm) | |
|
DBM25S743M | 20.9362 | |
6246 | 0.00000000 | Amphenol ICC (FCI) | DM | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | Mounting Brackets | DBM25S7 | - | Solder | - | download | RoHS non-compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 40 | Receptacle, Female Sockets | 2 | Gold | - | 7.5A | Phosphor Bronze | UL94 V-0 | Signal | 25 | 300V | Housing/Shell (Unthreaded) | Thermoplastic | Steel, Yellow Cadmium Plated | D-Sub | - | - | 3 (DB, B) | 0.318" (8.08mm) | ||
|
DBMF9W4PN | 10.7605 | |
1439 | 0.00000000 | Amphenol ICC (FCI) | DMW HE507 | Tray | Active | -55°C ~ 125°C | Free Hanging (In-Line) | - | DBMF9W4 | Green | Solder Cup | - | download | RoHS non-compliant | 1 (Unlimited) | EAR99 | 8536.69.8000 | 40 | Plug, Male Pins | 2 | Gold | - | 7.5A | Brass | UL94 V-0 | Signal and Power (Not Included) | 9 (5 + 4 Power) | 300V | Housing/Shell (Unthreaded) | Thermoplastic | Steel, Yellow Chromate Plated Cadmium | D-Sub, Combo | - | - | 3 (DB, B) - 9W4 | - | ||
|
DBMS13W3P300 | 6.9639 | |
8136 | 0.00000000 | Amphenol ICC (FCI) | DMW HE507 | Tray | Active | -55°C ~ 125°C | Through Hole | - | DBMS13W3 | - | Solder | - | download | RoHS non-compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 40 | Plug, Male Pins | 2 | Gold | - | 7.5A | Brass | UL94 V-0 | Signal and Power (Not Included) | 13 (10 + 3 Power) | 300V | Board Side | Thermoplastic | Steel | D-Sub, Combo | - | - | 3 (DB, B) - 13C3, 13W3 | - | ||
|
DBMS25SN | - | |
2609 | 0.00000000 | Amphenol ICC (FCI) | DM HE508 | Tray | Obsolete | -55°C ~ 155°C | Free Hanging (In-Line) | - | DBMS25 | - | Solder Cup | - | download | RoHS non-compliant | 1 (Unlimited) | EAR99 | 8536.69.8000 | 20 | Receptacle, Female Sockets | 2 | Gold | - | 7.5A per Contact | Brass | UL94 V-0 | Signal | 25 | 300V | Cable Side | Thermoplastic | Steel, Yellow Cadmium Plated | D-Sub | - | Machined | 3 (DB, B) | - | ||
|
DBO13W3P500G307JLF | - | |
4127 | 0.00000000 | Amphenol ICC (FCI) | DW | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | - | DBO13W3 | - | Solder | - | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 80 | Plug, Male Pins | 2 | Gold | - | - | - | - | Signal and Power | 13 (10 + 3 Power) | 300V | Board Side (4-40) | Thermoplastic | Steel, Tin Plated | D-Sub, Combo | - | - | 3 (DB, B) - 13C3, 13W3 | - | ||
|
DBO13W3S300H40LF | - | |
7735 | 0.00000000 | Amphenol ICC (FCI) | DW | Tray | Active | -55°C ~ 125°C | Through Hole | Board Lock | DBO13W3 | - | Solder | - | download | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 80 | Receptacle, Female Sockets | 2 | Gold | - | 7.5A, 40A | Brass | UL94 V-0 | Signal and Power | 13 (10 + 3 Power) | 300V | Board Side (4-40) | Thermoplastic | Steel, Nickel Plated | D-Sub, Combo | - | - | 3 (DB, B) - 13C3, 13W3 | - | |
|
DBO13W3S743M30LF | 14.9026 | |
3151 | 0.00000000 | Amphenol ICC (FCI) | DW | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | Mounting Brackets | DBO13W3 | - | Solder | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 80 | Receptacle, Female Sockets | 2 | Gold | - | 7.5A, 30A | Brass, Phosphor Bronze | UL94 V-0 | Signal and Power | 13 (10 + 3 Power) | 300V | Board Side (4-40) | Thermoplastic | Steel, Nickel Plated | D-Sub, Combo | - | - | 3 (DB, B) - 13C3, 13W3 | 0.318" (8.08mm) | ||
|
DBO17W2P300G30LF | 12.1717 | |
6123 | 0.00000000 | Amphenol ICC (FCI) | DW | Tray | Active | -55°C ~ 125°C | Through Hole | Board Lock, Grounding Indents | DBO17W2 | - | Solder | - | download | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 80 | Plug, Male Pins | 2 | Gold | - | 7.5A, 30A | Brass | UL94 V-0 | Signal and Power | 17 (15 + 2 Power) | 300V | Board Side (4-40) | Thermoplastic | Steel, Nickel Plated | D-Sub, Combo | - | - | 3 (DB, B) - 17W2 | - | |
|
DBO17W2P343G30LF | - | |
8050 | 0.00000000 | Amphenol ICC (FCI) | DW | Tray | Active | -55°C ~ 125°C | Through Hole | Board Lock, Grounding Indents | DBO17W2 | - | Solder | - | download | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 20 | Plug, Male Pins | 2 | Gold | - | 7.5A, 30A | Brass | UL94 V-0 | Signal and Power | 17 (15 + 2 Power) | 300V | Board Side (4-40) | Thermoplastic | Steel, Nickel Plated | D-Sub, Combo | - | - | 3 (DB, B) - 17W2 | - | |
|
DBO17W2P743G30LF | - | |
1771 | 0.00000000 | Amphenol ICC (FCI) | DW | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | Board Lock, Grounding Indents, Mounting Brackets | DBO17W2 | - | Solder | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 80 | Plug, Male Pins | 2 | Gold | - | 7.5A, 30A | Brass | UL94 V-0 | Signal and Power | 17 (15 + 2 Power) | 300V | Board Side (4-40) | Thermoplastic | Steel, Nickel Plated | D-Sub, Combo | - | - | 3 (DB, B) - 17W2 | 0.318" (8.08mm) | ||
|
DBO17W2S300G40LF | - | |
1848 | 0.00000000 | Amphenol ICC (FCI) | DW | Tray | Active | -55°C ~ 125°C | Through Hole | Board Lock | DBO17W2 | - | Solder | - | download | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 80 | Receptacle, Female Sockets | 2 | Gold | - | 7.5A, 40A | Brass | UL94 V-0 | Signal and Power | 17 (15 + 2 Power) | 300V | Board Side (4-40) | Thermoplastic | Steel, Nickel Plated | D-Sub, Combo | - | - | 3 (DB, B) - 17W2 | - | |
|
DBO5W5P300H30LF | - | |
6184 | 0.00000000 | Amphenol ICC (FCI) | DW | Tray | Active | -55°C ~ 125°C | Through Hole | Board Lock, Grounding Indents | DBO5W5 | - | Solder | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 80 | Plug, Male Pins | 1 | Gold | - | 30A | Brass | UL94 V-0 | Power | 5 (Power) | 300V | Board Side (4-40) | Thermoplastic | Steel, Nickel Plated | D-Sub, Combo | - | - | 3 (DB, B) - 5W5 | - | ||
|
DBO5W5P500G40LF | 12.1456 | |
4939 | 0.00000000 | Amphenol ICC (FCI) | DW | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | Board Lock, Grounding Indents, Mounting Brackets | DBO5W5 | - | Solder | - | download | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 80 | Plug, Male Pins | 1 | Gold | - | 40A | Brass | UL94 V-0 | Power | 5 (Power) | 300V | Board Side (4-40) | Thermoplastic | Steel, Nickel Plated | D-Sub, Combo | - | - | 3 (DB, B) - 5W5 | 0.458" (11.64mm) | |
|
DBO5W5P500H30LF | - | |
9293 | 0.00000000 | Amphenol ICC (FCI) | DW | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | Board Lock, Grounding Indents, Mounting Brackets | DBO5W5 | - | Solder | - | download | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 20 | Plug, Male Pins | 1 | Gold | - | 30A | Brass | UL94 V-0 | Power | 5 (Power) | 300V | Board Side (4-40) | Thermoplastic | Steel, Nickel Plated | D-Sub, Combo | - | - | 3 (DB, B) - 5W5 | 0.458" (11.64mm) | |
|
DBO5W5S93C5G40LF | 21.4899 | |
9500 | 0.00000000 | Amphenol ICC (FCI) | DW | Tray | Active | -55°C ~ 125°C | Through Hole | Board Lock | DBO5W5 | - | Press-Fit | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 80 | Receptacle, Female Sockets | 1 | Gold | - | 40A | Brass | UL94 V-0 | Power | 5 (Power) | 300V | Board Side (4-40) | Thermoplastic | Steel, Nickel Plated | D-Sub, Combo | - | - | 3 (DB, B) - 5W5 | - | ||
|
DBO9W4P543A40LF | - | |
3877 | 0.00000000 | Amphenol ICC (FCI) | DW | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | Grounding Indents | DBO9W4 | - | Solder | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 20 | Plug, Male Pins | 2 | Gold | - | 7.5A, 40A | Brass | UL94 V-0 | Signal and Power | 9 (5 + 4 Power) | 300V | Board Side (4-40) | Thermoplastic | Steel, Nickel Plated | D-Sub, Combo | - | - | 3 (DB, B) - 9W4 | 0.406" (10.30mm) | ||
|
DBO9W4S500G30LF | - | |
2810 | 0.00000000 | Amphenol ICC (FCI) | DW | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | Board Lock, Mounting Brackets | DBO9W4 | - | Solder | - | download | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 80 | Receptacle, Female Sockets | 2 | Gold | - | 7.5A, 30A | Brass, Phosphor Bronze | UL94 V-0 | Signal and Power | 9 (5 + 4 Power) | 300V | Board Side (4-40) | Thermoplastic | Steel, Nickel Plated | D-Sub, Combo | - | - | 3 (DB, B) - 9W4 | 0.406" (10.30mm) | |
|
DBP25P064LORLF | - | |
4745 | 0.00000000 | Amphenol ICC (FCI) | DP | Tray | Obsolete | -55°C ~ 125°C | Free Hanging (In-Line) | - | DBP25P064 | - | Solder Cup | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.8000 | 100 | Plug, Male Pins | 2 | Gold, GXT™ | Flash | 7.5A | Copper Alloy | UL94 V-0 | Signal | 25 | 300V | Housing/Shell (Unthreaded) | Thermoplastic | - | D-Sub | - | - | 3 (DB, B) | - | ||
|
DBP25P364LORLF | - | |
1168 | 0.00000000 | Amphenol ICC (FCI) | DP | Tray | Obsolete | -55°C ~ 125°C | Through Hole | - | DBP25P364 | - | Solder | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 100 | Plug, Male Pins | 2 | Gold, GXT™ | Flash | 7.5A | Copper Alloy | UL94 V-0 | Signal | 25 | 300V | Housing/Shell (Unthreaded) | Thermoplastic | - | D-Sub | - | - | 3 (DB, B) | - | ||
|
DBP25S064TLF | - | |
6561 | 0.00000000 | Amphenol ICC (FCI) | DP | Bulk | Active | -55°C ~ 125°C | Free Hanging (In-Line) | - | DBP25S064 | - | Solder Cup | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.8000 | 200 | Receptacle, Female Sockets | 2 | Gold, GXT™ | Flash | 7.5A | Copper Alloy | UL94 V-0 | Signal | 25 | 300V | Housing/Shell (Unthreaded) | Thermoplastic | Steel, Tin Plated | D-Sub | - | - | 3 (DB, B) | - | ||
|
DBP25S364LORLF | - | |
5190 | 0.00000000 | Amphenol ICC (FCI) | DP | Tray | Obsolete | -55°C ~ 125°C | Through Hole | - | DBP25S364 | - | Solder | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 100 | Receptacle, Female Sockets | 2 | Gold, GXT™ | Flash | 7.5A | Copper Alloy | UL94 V-0 | Signal | 25 | 300V | Housing/Shell (Unthreaded) | Thermoplastic | - | D-Sub | - | - | 3 (DB, B) | - | ||
|
DBPL25P564CTXLF | 10.3226 | |
3869 | 0.00000000 | Amphenol ICC (FCI) | DP | Bulk | Active | -55°C ~ 125°C | Through Hole, Right Angle | Grounding Indents | DBPL25P564 | - | Solder | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 100 | Plug, Male Pins | 2 | Gold, GXT™ | Flash | 7.5A | Copper Alloy | UL94 V-0 | Signal | 25 | 300V | Board Side (M3) | Thermoplastic | Steel, Tin Plated | D-Sub | - | - | 3 (DB, B) | 0.406" (10.30mm) | ||
|
DBPL25S565MTLF | 18.8202 | |
4144 | 0.00000000 | Amphenol ICC (FCI) | DP | Bulk | Active | -55°C ~ 125°C | Through Hole, Right Angle | Mounting Brackets | DBPL25S565 | - | Solder | - | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 180 | Receptacle, Female Sockets | 2 | Gold, GXT™ | 30.0µin (0.76µm) | 7.5A per Contact | Copper Alloy | UL94 V-0 | Signal | 25 | 1000V | Board Side (M3) | Thermoplastic | Steel, Tin Plated | D-Sub | - | - | 3 (DB, B) | - | ||
|
DBPS25P365128LF | - | |
5203 | 0.00000000 | Amphenol ICC (FCI) | DP | Bulk | Obsolete | -55°C ~ 125°C | Through Hole | - | DBPS25P365 | - | Solder | - | - | 1 (Unlimited) | EAR99 | 8536.69.4040 | 200 | Plug, Male Pins | 2 | Gold, GXT™ | 30.0µin (0.76µm) | 7.5A | Copper Alloy | UL94 V-0 | Signal | 25 | 300V | Board Side | Thermoplastic | - | D-Sub | - | - | 3 (DB, B) | - |
