Single Diodes(57622)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Mounting Type | Package / Case | Base Product Number | Technology | Supplier Device Package | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | REACH Status | Other Names | ECCN | HTSUS | Standard Package | Speed | Voltage - DC Reverse (Vr) (Max) | Voltage - Forward (Vf) (Max) @ If | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Operating Temperature - Junction | Current - Average Rectified (Io) | Capacitance @ Vr, F |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
UG1A-M3/73 | - |  |
5848 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tape & Box (TB) | Active | Through Hole | DO-204AL, DO-41, Axial | UG1 | Standard | DO-204AL (DO-41) | - | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 3,000 | Fast Recovery =< 500ns, > 200mA (Io) | 50 V | 950 mV @ 1 A | 25 ns | 5 µA @ 50 V | -55°C ~ 150°C | 1A | 7pF @ 4V, 1MHz | ||
|
UG1C-M3/73 | - | |
6031 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tape & Box (TB) | Active | Through Hole | DO-204AL, DO-41, Axial | UG1 | Standard | DO-204AL (DO-41) | - | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 3,000 | Fast Recovery =< 500ns, > 200mA (Io) | 150 V | 950 mV @ 1 A | 25 ns | 5 µA @ 150 V | -55°C ~ 150°C | 1A | 7pF @ 4V, 1MHz | ||
 |
UG4B-M3/73 | - | |
4612 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tape & Box (TB) | Active | Through Hole | DO-201AD, Axial | UG4 | Standard | DO-201AD | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 1,000 | Fast Recovery =< 500ns, > 200mA (Io) | 100 V | 950 mV @ 4 A | 15 ns | 5 µA @ 100 V | -55°C ~ 150°C | 4A | 20pF @ 4V, 1MHz | ||
 |
MURS320-M3/9AT | 0.2363 | |
8713 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tape & Reel (TR) | Active | Surface Mount | DO-214AB, SMC | MURS320 | Standard | DO-214AB (SMC) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 3,500 | Fast Recovery =< 500ns, > 200mA (Io) | 200 V | 875 mV @ 3 A | 35 ns | 5 µA @ 200 V | -65°C ~ 175°C | 3A | - | ||
|
RGP02-16E-M3/54 | - | |
6123 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tape & Reel (TR) | Obsolete | Through Hole | DO-204AL, DO-41, Axial | RGP02 | Standard | DO-204AL (DO-41) | - | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0070 | 5,500 | Fast Recovery =< 500ns, > 200mA (Io) | 1600 V | 1.8 V @ 100 mA | 300 ns | 5 µA @ 1600 V | -65°C ~ 175°C | 500mA | 5pF @ 4V, 1MHz | ||
|
RGP02-20E-M3/54 | - | |
7711 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tape & Reel (TR) | Obsolete | Through Hole | DO-204AL, DO-41, Axial | RGP02 | Standard | DO-204AL (DO-41) | - | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0070 | 5,500 | Fast Recovery =< 500ns, > 200mA (Io) | 2000 V | 1.8 V @ 100 mA | 300 ns | 5 µA @ 2000 V | -65°C ~ 175°C | 500mA | 5pF @ 4V, 1MHz | ||
|
RGP10DHM3/54 | - | |
7603 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101, Superectifier® | Tape & Reel (TR) | Obsolete | Through Hole | DO-204AL, DO-41, Axial | RGP10 | Standard | DO-204AL (DO-41) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 5,500 | Fast Recovery =< 500ns, > 200mA (Io) | 200 V | 1.3 V @ 1 A | 150 ns | 5 µA @ 200 V | -65°C ~ 175°C | 1A | 15pF @ 4V, 1MHz | ||
|
RGP10D-M3/54 | - | |
2330 | 0.00000000 | Vishay General Semiconductor - Diodes Division | SUPERECTIFIER® | Tape & Reel (TR) | Obsolete | Through Hole | DO-204AL, DO-41, Axial | RGP10 | Standard | DO-204AL (DO-41) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 5,500 | Fast Recovery =< 500ns, > 200mA (Io) | 200 V | 1.3 V @ 1 A | 150 ns | 5 µA @ 200 V | -65°C ~ 175°C | 1A | 15pF @ 4V, 1MHz | ||
|
RGP10GHM3/54 | - | |
1972 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101, Superectifier® | Tape & Reel (TR) | Obsolete | Through Hole | DO-204AL, DO-41, Axial | RGP10 | Standard | DO-204AL (DO-41) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 5,500 | Fast Recovery =< 500ns, > 200mA (Io) | 400 V | 1.3 V @ 1 A | 150 ns | 5 µA @ 400 V | -65°C ~ 175°C | 1A | 15pF @ 4V, 1MHz | ||
|
RGP10JHM3/54 | - | |
6459 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101, Superectifier® | Tape & Reel (TR) | Obsolete | Through Hole | DO-204AL, DO-41, Axial | RGP10 | Standard | DO-204AL (DO-41) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 5,500 | Fast Recovery =< 500ns, > 200mA (Io) | 600 V | 1.3 V @ 1 A | 250 ns | 5 µA @ 600 V | -65°C ~ 175°C | 1A | 15pF @ 4V, 1MHz | ||
 |
RS07J-GS18 | 0.4100 | |
1 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | DO-219AB | RS07 | Standard | DO-219AB (SMF) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0070 | 10,000 | Fast Recovery =< 500ns, > 200mA (Io) | 600 V | 1.15 V @ 700 mA | 250 ns | 10 µA @ 600 V | -55°C ~ 150°C | 500mA | 9pF @ 4V, 1MHz | ||
 |
RS2A-M3/5BT | 0.1142 | |
1482 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tape & Reel (TR) | Active | Surface Mount | DO-214AA, SMB | RS2A | Standard | DO-214AA (SMB) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 3,200 | Fast Recovery =< 500ns, > 200mA (Io) | 50 V | 1.3 V @ 1.5 A | 150 ns | 5 µA @ 50 V | -55°C ~ 150°C | 1.5A | 20pF @ 4V, 1MHz | ||
|
S07D-M-18 | 0.1016 | |
6748 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | DO-219AB | S07 | Standard | DO-219AB (SMF) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 50,000 | Standard Recovery >500ns, > 200mA (Io) | 200 V | 1.1 V @ 1 A | 1.8 µs | 10 µA @ 200 V | -55°C ~ 150°C | 700mA | 4pF @ 4V, 1MHz | ||
|
S07G-M-18 | 0.3700 | |
7 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | DO-219AB | S07 | Standard | DO-219AB (SMF) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 10,000 | Standard Recovery >500ns, > 200mA (Io) | 400 V | 1.1 V @ 1 A | 1.8 µs | 10 µA @ 200 V | -55°C ~ 150°C | 700mA | 4pF @ 4V, 1MHz | ||
 |
S1M-M3/5AT | 0.3400 | |
27 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tape & Reel (TR) | Active | Surface Mount | DO-214AC, SMA | S1M | Standard | DO-214AC (SMA) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 7,500 | Standard Recovery >500ns, > 200mA (Io) | 1000 V | 1.1 V @ 1 A | 1.8 µs | 5 µA @ 1000 V | -55°C ~ 150°C | 1A | 12pF @ 4V, 1MHz | ||
|
S2G-M3/5BT | 0.0888 | |
3437 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tape & Reel (TR) | Active | Surface Mount | DO-214AA, SMB | S2G | Standard | DO-214AA (SMB) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 3,200 | Standard Recovery >500ns, > 200mA (Io) | 400 V | 1.15 V @ 1.5 A | 2 µs | 1 µA @ 400 V | -55°C ~ 150°C | 1.5A | 16pF @ 4V, 1MHz | ||
|
S5M-M3/9AT | 0.1549 | |
5830 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tape & Reel (TR) | Active | Surface Mount | DO-214AB, SMC | S5M | Standard | DO-214AB (SMC) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 3,500 | Standard Recovery >500ns, > 200mA (Io) | 1000 V | 1.15 V @ 5 A | 2.5 µs | 10 µA @ 1000 V | -55°C ~ 150°C | 5A | 40pF @ 4V, 1MHz | ||
|
SB2J-M3/5BT | 0.1160 | |
5722 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tape & Reel (TR) | Active | Surface Mount | DO-214AA, SMB | SB2 | Standard | DO-214AA (SMB) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 3,200 | Standard Recovery >500ns, > 200mA (Io) | 600 V | 1.15 V @ 2 A | 2 µs | 1 µA @ 600 V | -55°C ~ 150°C | 2A | 16pF @ 4V, 1MHz | ||
|
SB2M-M3/5BT | 0.1160 | |
7744 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tape & Reel (TR) | Active | Surface Mount | DO-214AA, SMB | SB2 | Standard | DO-214AA (SMB) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 3,200 | Standard Recovery >500ns, > 200mA (Io) | 1000 V | 1.15 V @ 2 A | 2 µs | 1 µA @ 1000 V | -55°C ~ 150°C | 2A | 16pF @ 4V, 1MHz | ||
 |
SD101AWS-G3-18 | 0.4000 | |
10 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tape & Reel (TR) | Active | Surface Mount | SC-76, SOD-323 | SD101 | Schottky | SOD-323 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0070 | 10,000 | Small Signal =< 200mA (Io), Any Speed | 60 V | 1 V @ 15 mA | 1 ns | 200 nA @ 50 V | -55°C ~ 125°C | 30mA | 2pF @ 0V, 1MHz | ||
 |
SD101CW-G3-18 | 0.0577 | |
6670 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tape & Reel (TR) | Active | Surface Mount | SOD-123 | SD101 | Schottky | SOD-123 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0070 | 10,000 | Small Signal =< 200mA (Io), Any Speed | 40 V | 900 mV @ 15 mA | 1 ns | 200 nA @ 30 V | -55°C ~ 125°C | 30mA | 2.2pF @ 0V, 1MHz | ||
|
SD101CW-HE3-18 | 0.0534 | |
4918 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | SOD-123 | SD101 | Schottky | SOD-123 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0070 | 10,000 | Small Signal =< 200mA (Io), Any Speed | 40 V | 900 mV @ 15 mA | 1 ns | 200 nA @ 30 V | -55°C ~ 125°C | 30mA | 2.2pF @ 0V, 1MHz | ||
|
SD103BW-G3-18 | 0.0612 | |
2482 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tape & Reel (TR) | Active | Surface Mount | SOD-123 | SD103 | Schottky | SOD-123 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0070 | 10,000 | Fast Recovery =< 500ns, > 200mA (Io) | 30 V | 600 mV @ 200 mA | 10 ns | 5 µA @ 20 V | -55°C ~ 125°C | 350mA | 50pF @ 0V, 1MHz | ||
 |
ACGRKM4006-HF | 0.0800 | |
7209 | 0.00000000 | Comchip Technology | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | SOD-123T | ACGRKM4006 | Standard | KM/SOD-123F | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 2,500 | Standard Recovery >500ns, > 200mA (Io) | 800 V | 1.1 V @ 1 A | 5 µA @ 800 V | -55°C ~ 150°C | 1A | 15pF @ 4V, 1MHz | |||
 |
VS-150SQ030 | - | |
8925 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Bulk | Obsolete | Through Hole | DO-204AR, Axial | 150SQ030 | Standard | DO-204AR | download | ROHS3 Compliant | 1 (Unlimited) | VS150SQ030 | EAR99 | 8541.10.0080 | 300 | Standard Recovery >500ns, > 200mA (Io) | 30 V | 540 mV @ 15 A | 1.75 mA @ 30 V | -55°C ~ 150°C | 15A | 900pF @ 5V, 1MHz | |||
|
VS-1N2160 | - | |
2167 | 0.00000000 | Vishay General Semiconductor - Diodes Division | * | Bulk | Active | 1N2160 | - | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS1N2160 | EAR99 | 8541.10.0080 | 100 | |||||||||||||
|
VS-1N5820 | - | |
5398 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Bulk | Obsolete | Through Hole | DO-201AD, Axial | 1N5820 | Schottky | DO-201AD (C-16) | download | ROHS3 Compliant | 1 (Unlimited) | VS1N5820 | EAR99 | 8541.10.0080 | 500 | Fast Recovery =< 500ns, > 200mA (Io) | 20 V | 475 mV @ 3 A | 2 mA @ 20 V | -65°C ~ 150°C | 3A | 350pF @ 5V, 1MHz | |||
|
VS-20MQ060NPBF | - | |
6929 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Bulk | Obsolete | Surface Mount | DO-214AC, SMA | 20MQ060 | Schottky | DO-214AC (SMA) | download | ROHS3 Compliant | 1 (Unlimited) | VS20MQ060NPBF | EAR99 | 8541.10.0080 | 1,000 | Fast Recovery =< 500ns, > 200mA (Io) | 60 V | 780 mV @ 2 A | 50 µA @ 600 V | -55°C ~ 150°C | 2A | 31pF @ 10V, 1MHz | |||
 |
VS-25F80M | 11.4300 | |
9211 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Bulk | Active | Chassis, Stud Mount | DO-203AA, DO-4, Stud | 25F80 | Standard | DO-203AA (DO-4) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 100 | Standard Recovery >500ns, > 200mA (Io) | 800 V | 1.3 V @ 78 A | -65°C ~ 175°C | 25A | - | ||||
 |
VS-301URA200 | - | |
2518 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Bulk | Obsolete | Stud Mount | DO-205AB, DO-9, Stud | 301URA200 | Standard, Reverse Polarity | DO-205AB (DO-9) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS301URA200 | EAR99 | 8541.10.0080 | 12 | Standard Recovery >500ns, > 200mA (Io) | 2000 V | 1.46 V @ 942 A | -40°C ~ 180°C | 330A | - |
