Diodes(1039)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Tolerance | Operating Temperature | Mounting Type | Package / Case | Base Product Number | Technology | Power - Max | Supplier Device Package | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | Other Names | ECCN | HTSUS | Standard Package | Configuration | Speed | Diode Configuration | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) (per Diode) | Voltage - Forward (Vf) (Max) @ If | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Operating Temperature - Junction | Current - Average Rectified (Io) | Capacitance @ Vr, F | Voltage - Zener (Nom) (Vz) | Impedance (Max) (Zzt) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
DZ5S120D0R | - |  |
4778 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Discontinued at SIC | - | - | Surface Mount | SOT-665 | DZ5S120 | 150 mW | SSMini5-F4-B | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0050 | 8,000 | 2 Pair Common Anode | 1 V @ 10 mA | 50 nA @ 9 V | 12 V | 30 Ohms | |||||||||||
|
DZ2703900L | - | |
4329 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Discontinued at SIC | ±5% | - | Surface Mount | 2-SMD, Flat Lead | DZ27039 | 120 mW | SSSMini2-F4-B | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0050 | 10,000 | 1 V @ 10 mA | 10 µA @ 1 V | 3.91 V | 130 Ohms | ||||||||||||
|
DZ2S24000L | - | |
5185 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Discontinued at SIC | ±5% | - | Surface Mount | SC-79, SOD-523 | DZ2S24 | 150 mW | SSMini2-F5-B | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0050 | 3,000 | 1 V @ 10 mA | 50 nA @ 19 V | 24 V | 100 Ohms | ||||||||||||
 |
MAZ30360HL | - | |
3744 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Obsolete | ±6% | - | Surface Mount | TO-236-3, SC-59, SOT-23-3 | MAZ3036 | 200 mW | Mini3-G1 | download | 1 (Unlimited) | EAR99 | 8541.10.0050 | 3,000 | 900 mV @ 10 mA | 10 µA @ 1 V | 3.6 V | 130 Ohms | |||||||||||||
 |
DZ4J180K0R | - | |
6894 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Obsolete | - | - | Surface Mount | 4-SMD, Flat Leads | DZ4J18 | 200 mW | SMini4-F3-B | download | 1 (Unlimited) | EAR99 | 8541.10.0050 | 3,000 | 2 Independent | 1 V @ 10 mA | 50 nA @ 13 V | 18 V | 60 Ohms | ||||||||||||
 |
DB3J407K0L | - | |
8206 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Discontinued at SIC | Surface Mount | SC-85 | DB3J407K | Schottky | SMini3-F2-B | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0070 | 3,000 | Fast Recovery =< 500ns, > 200mA (Io) | 40 V | 550 mV @ 500 mA | 5 ns | 100 µA @ 35 V | 125°C (Max) | 500mA | 12pF @ 10V, 1MHz | ||||||||||
|
DB3Y313KEL | - | |
1152 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Obsolete | Surface Mount | TO-236-3, SC-59, SOT-23-3 | DB3Y313 | Schottky | SOT-23-3 | download | 1 (Unlimited) | EAR99 | 8541.10.0070 | 3,000 | Small Signal =< 200mA (Io), Any Speed | 30 V | 550 mV @ 200 mA | 1.5 ns | 50 µA @ 30 V | 125°C (Max) | 200mA | 3.8pF @ 10V, 1MHz | |||||||||||
 |
DZ2W09100L | - | |
7899 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Discontinued at SIC | ±5% | - | Surface Mount | SOD-123F | DZ2W091 | 1 W | Mini2-F3-B | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0050 | 3,000 | 1.2 V @ 200 mA | 10 µA @ 5 V | 9.1 V | 30 Ohms | ||||||||||||
 |
MAZ20750AG | - | |
7952 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Obsolete | ±6% | - | Through Hole | DO-204AL, DO-41, Axial | MAZ2075 | 1 W | DO41-A1 | download | 1 (Unlimited) | EAR99 | 8541.10.0050 | 7,000 | 1 V @ 200 mA | 10 µA @ 3 V | 7.5 V | 5 Ohms | |||||||||||||
 |
DB2J20800L | - | |
3122 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Discontinued at SIC | Surface Mount | SC-90, SOD-323F | DB2J208 | Schottky | SMini2-F5-B | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0070 | 3,000 | Fast Recovery =< 500ns, > 200mA (Io) | 20 V | 420 mV @ 500 mA | 4.3 ns | 200 µA @ 20 V | 125°C (Max) | 500mA | 12pF @ 10V, 1MHz | ||||||||||
 |
MA6X71800L | - | |
1315 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Obsolete | Surface Mount | SOT-23-6 | MA6X718 | Schottky | MINI6-G1 | download | 1 (Unlimited) | EAR99 | 8541.10.0070 | 3,000 | Small Signal =< 200mA (Io), Any Speed | 3 Independent | 30 V | 30mA (DC) | 1 V @ 30 mA | 1 ns | 1 µA @ 30 V | 125°C (Max) | |||||||||||
|
DZ2W03600L | - | |
8529 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Discontinued at SIC | ±5% | - | Surface Mount | SOD-123F | DZ2W036 | 1 W | Mini2-F3-B | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0050 | 3,000 | 1.2 V @ 200 mA | 60 µA @ 1 V | 3.6 V | 100 Ohms | ||||||||||||
 |
DA37103E0L | - | |
6572 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Discontinued at SIC | Surface Mount | SOT-723 | DA37103 | Standard | SSSMini3-F2-B | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0070 | 10,000 | Small Signal =< 200mA (Io), Any Speed | 1 Pair Common Cathode | 80 V | 100mA (DC) | 1.2 V @ 100 mA | 10 ns | 100 nA @ 80 V | 150°C (Max) | ||||||||||
|
DB3X207K0L | - | |
2316 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Discontinued at SIC | Surface Mount | TO-236-3, SC-59, SOT-23-3 | DB3X207K | Standard | MINI3-G3-B | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0080 | 3,000 | Fast Recovery =< 500ns, > 200mA (Io) | 20 V | 400 mV @ 1 A | 12 ns | 1.5 mA @ 6 V | 125°C (Max) | 1A | 43pF @ 10V, 1MHz | ||||||||||
 |
MA2C19600E | - | |
5581 | 0.00000000 | Panasonic Electronic Components | - | Cut Tape (CT) | Obsolete | Through Hole | DO-204AG, DO-34, Axial | MA2C196 | Standard | DO34-A1 | download | 1 (Unlimited) | EAR99 | 8541.10.0070 | 5,000 | Small Signal =< 200mA (Io), Any Speed | 50 V | 1.2 V @ 100 mA | 200 µs | 10 nA @ 50 V | 200°C (Max) | 100mA | 4pF @ 0V, 1MHz | |||||||||||
 |
MA4X86200L | - | |
6178 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Obsolete | Surface Mount | TO-253-4, TO-253AA | MA4X862 | Standard | Mini4-G1 | download | 1 (Unlimited) | EAR99 | 8541.10.0070 | 3,000 | Small Signal =< 200mA (Io), Any Speed | 2 Independent | 35 V | 100mA (DC) | 1 V @ 100 mA | 100 nA @ 33 V | -25°C ~ 85°C | ||||||||||||
|
DB3X407K0L | - | |
5954 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Discontinued at SIC | Surface Mount | TO-236-3, SC-59, SOT-23-3 | DB3X407K | Schottky | MINI3-G3-B | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0070 | 3,000 | Fast Recovery =< 500ns, > 200mA (Io) | 40 V | 550 mV @ 500 mA | 3.6 ns | 100 µA @ 35 V | 125°C (Max) | 500mA | 10.5pF @ 10V, 1MHz | ||||||||||
|
MAS3132EGL | - | |
7890 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Obsolete | Surface Mount | SOT-723 | MAS3132 | Standard | SSSMini3-F2 | download | 1 (Unlimited) | EAR99 | 8541.10.0070 | 10,000 | Small Signal =< 200mA (Io), Any Speed | 1 Pair Common Cathode | 80 V | 100mA (DC) | 1.2 V @ 100 mA | 3 ns | 100 nA @ 75 V | 150°C (Max) | |||||||||||
 |
MAZ80390HL | - | |
4605 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Obsolete | ±5% | - | Surface Mount | SC-90, SOD-323F | MAZ8039 | 150 mW | SMini2-F1 | download | 1 (Unlimited) | EAR99 | 8541.10.0050 | 3,000 | 1 V @ 10 mA | 10 µA @ 1 V | 3.9 V | 130 Ohms | |||||||||||||
 |
MA3D799 | - | |
3287 | 0.00000000 | Panasonic Electronic Components | - | Bulk | Obsolete | Through Hole | TO-220-3 Full Pack | MA3D79 | Schottky | TO-220D-A1 | download | 1 (Unlimited) | EAR99 | 8541.10.0080 | 50 | Fast Recovery =< 500ns, > 200mA (Io) | 1 Pair Common Cathode | 30 V | 10A | 470 mV @ 5 A | 3 mA @ 30 V | -40°C ~ 125°C | ||||||||||||
 |
DB2731400L | - | |
5339 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Discontinued at SIC | Surface Mount | 2-SMD, Flat Lead | DB27314 | Schottky | SSSMini2-F4-B | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0070 | 10,000 | Small Signal =< 200mA (Io), Any Speed | 30 V | 1 V @ 30 mA | 1 ns | 300 nA @ 30 V | 125°C (Max) | 30mA | 1.5pF @ 10V, 1MHz | ||||||||||
|
MA3D749 | - | |
1329 | 0.00000000 | Panasonic Electronic Components | - | Bulk | Obsolete | Through Hole | TO-220-3 Full Pack | MA3D74 | Schottky | TO-220D-A1 | download | 1 (Unlimited) | EAR99 | 8541.10.0080 | 50 | Fast Recovery =< 500ns, > 200mA (Io) | 1 Pair Common Cathode | 40 V | 5A | 550 mV @ 2.5 A | 1 mA @ 40 V | -40°C ~ 125°C | ||||||||||||
 |
MA27D2700L | - | |
9942 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Obsolete | Surface Mount | 2-SMD, Flat Lead | MA27D27 | Schottky | SSSMini2-F2 | download | 1 (Unlimited) | EAR99 | 8541.10.0070 | 10,000 | Small Signal =< 200mA (Io), Any Speed | 20 V | 580 mV @ 100 mA | 1 ns | 300 nA @ 10 V | 150°C (Max) | 100mA | 11pF @ 0V, 1MHz | |||||||||||
|
DB3X316K0L | - | |
9512 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Discontinued at SIC | Surface Mount | TO-236-3, SC-59, SOT-23-3 | DB3X316K | Schottky | MINI3-G3-B | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0070 | 3,000 | Small Signal =< 200mA (Io), Any Speed | 30 V | 550 mV @ 100 mA | 800 ps | 15 µA @ 30 V | 125°C (Max) | 100mA | 2pF @ 10V, 1MHz | ||||||||||
|
MAZ33600ML | 0.2800 | |
18 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Obsolete | ±6% | - | Surface Mount | TO-236-3, SC-59, SOT-23-3 | MAZ336 | 200 mW | Mini3-G1 | download | 1 (Unlimited) | EAR99 | 8541.10.0050 | 3,000 | 900 mV @ 10 mA | 50 nA @ 25 V | 36 V | 90 Ohms | |||||||||||||
 |
MA3J14700L | - | |
3828 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Obsolete | Surface Mount | SC-85 | MA3J147 | Standard | SMini3-F1 | download | 1 (Unlimited) | EAR99 | 8541.10.0070 | 3,000 | Small Signal =< 200mA (Io), Any Speed | 1 Pair Series Connection | 80 V | 100mA (DC) | 1.2 V @ 100 mA | 3 ns | 100 nA @ 75 V | 150°C (Max) | |||||||||||
|
DZ2J030M0L | - | |
8986 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Discontinued at SIC | ±2.5% | - | Surface Mount | SC-90, SOD-323F | DZ2J030 | 200 mW | SMini2-F5-B | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0050 | 3,000 | 1 V @ 10 mA | 50 µA @ 1 V | 3 V | 120 Ohms | ||||||||||||
|
MA6X1250GL | - | |
4531 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Obsolete | Surface Mount | - | MA6X125 | Standard | - | - | 1 (Unlimited) | Q5021191 | EAR99 | 8541.10.0070 | 3,000 | Small Signal =< 200mA (Io), Any Speed | 2 Pair Series Connection | 40 V | 100mA (DC) | 1.2 V @ 100 mA | 150 ns | 100 nA @ 40 V | 150°C (Max) | ||||||||||
 |
DB2S30800L | - | |
5404 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Discontinued at SIC | Surface Mount | SC-79, SOD-523 | DB2S308 | Schottky | SSMini2-F5-B | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0070 | 3,000 | Small Signal =< 200mA (Io), Any Speed | 30 V | 420 mV @ 100 mA | 1.3 ns | 120 µA @ 30 V | 125°C (Max) | 100mA | 2.9pF @ 10V, 1MHz | ||||||||||
|
DB3J201K0L | - | |
5657 | 0.00000000 | Panasonic Electronic Components | - | Tape & Reel (TR) | Discontinued at SIC | Surface Mount | SC-85 | DB3J201 | Schottky | SMini3-F2-B | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0070 | 3,000 | Fast Recovery =< 500ns, > 200mA (Io) | 20 V | 550 mV @ 500 mA | 4.3 ns | 10 µA @ 10 V | 125°C (Max) | 500mA | 12pF @ 10V, 1MHz |
