Advantech 96MPXE-2.1-16M36 Microprocessors:A Comprehensive Guide

Advantech 96MPXE-2.1-16M36 +BOM

The Advantech 96MPXE-2.1-16M36 is a high-performance industrial computing solution. Designed to work seamlessly with processors like the Intel Xeon Silver 4116, it excels in multi-tasking and data processing, leveraging the CPU's 12 cores and 24 threads for efficient operation. With support for DDR4 - 2400 ECC memory, it ensures data integrity even in demanding applications, with a maximum capacity of 768GB across six channels. Featuring 48 PCI Express 3.0 lanes, the 96MPXE-2.1-16M36 offers extensive expandability, allowing users to integrate various expansion cards for enhanced functionality. Its robust heat dissipation design caters to the processor's 85W power consumption, ensuring stable operation under high loads. Ideal for industrial automation, smart energy management, and other critical applications, this model combines reliability, scalability, and advanced processing capabilities to meet complex industrial requirements. industrial requirements.

Advantech 96MPXE-2.1-16M36's Features

Processor Compatibility: It is very likely designed to be compatible with the Intel Xeon Silver 4116 processor, and it can fully leverage the multi-task processing capability of this processor with 12 cores and 24 threads. It supports a base frequency of 2.10GHz and a maximum turbo frequency of 3.00GHz, meeting the requirements of complex computing tasks.
Memory Performance: According to the memory specifications of the processor, it is expected to support DDR4 - 2400 memory. The maximum memory capacity can reach 768GB. The 6-channel memory design can effectively increase the memory bandwidth, and it supports ECC memory to ensure data accuracy. It is suitable for application scenarios with high requirements for data reliability, such as data processing in servers and industrial control.
Expansion Capability: Considering the expandability of the processor, the motherboard may support a 2S (dual-channel) configuration and provide 48 PCI Express 3.0 channels, making it convenient for users to connect various expansion cards, such as high-performance graphics cards for graphics processing, professional network cards to meet the needs of high-speed network communication, and storage expansion cards to achieve large-capacity data storage.
Heat Dissipation Design: Given the 85W power consumption of the processor, the motherboard should be equipped with an efficient heat dissipation solution to ensure stable operation within the temperature limit of T_CASE 76°C. This prevents a decrease in system performance or hardware damage due to overheating, ensuring the continuous and stable operation of industrial applications.
Support for Advanced Technologies: By virtue of the advanced technologies integrated in the processor, the motherboard is highly likely to support Intel® Speed Shift Technology for more intelligent frequency adjustment, Intel® vPro™ Technology for remote management and security protection, and Intel® Hyper - Threading Technology to improve multi-thread processing efficiency. At the same time, in terms of security, relying on features such as Intel® AES New Instructions and Intel® Trusted Execution Technology of the processor, it enhances the encryption of system data and the security of the execution environment.

Advantech 96MPXE-2.1-16M36's Applications

Industrial Automation
In manufacturing plants, it can be used to control complex production lines. For example, in automotive manufacturing, it can manage the coordination of multiple robotic arms, ensuring precise and efficient assembly operations. The high processing power of the associated Intel Xeon Silver 4116 processor enables real-time data processing of sensor information from various parts of the production line, such as temperature, pressure, and position sensors. The support for ECC memory ensures data integrity during critical control operations.
In process industries like chemical or pharmaceutical production, it can handle the control and monitoring of complex chemical reactions. The motherboard's expandability allows for the connection of additional I/O modules for controlling valves, pumps, and other process equipment, while the advanced security features help protect the integrity of production control systems.
Smart Energy Management
In power generation facilities, it can be used to manage the operation of generators and power distribution systems. For instance, in wind farms, it can monitor and control the operation of wind turbines, adjusting their speed and orientation based on wind conditions. The motherboard's support for high-speed communication interfaces, such as through the PCI Express 3.0 channels, enables seamless integration with power grid management systems. In smart grid applications, it can handle the bidirectional communication between the grid and end-users, facilitating energy management and optimization.
In solar power plants, it can manage the operation of solar panels, tracking the sun's position to maximize energy generation. The reliability features, such as ECC memory and advanced security, are crucial for ensuring the stable operation of the energy management system.
Transportation and Logistics
In intelligent transportation systems, it can be used for traffic signal control. The high processing power allows for real-time analysis of traffic flow data from cameras and sensors, enabling dynamic adjustment of traffic signals to optimize traffic flow. The motherboard's expandability can support additional communication modules for connecting to traffic management centers and other transportation infrastructure.
In logistics warehouses, it can manage the operation of automated storage and retrieval systems. The multi-core processing capabilities of the associated processor can handle the complex algorithms required for inventory management, order processing, and the control of robotic forklifts and conveyors. The security features can protect the warehouse management system from unauthorized access.
Medical Imaging and Healthcare IT
In medical imaging devices such as CT scanners and MRI machines, it can process the large amounts of data generated during scans. The high memory bandwidth and processing power are essential for real-time image reconstruction and analysis. The motherboard's expandability can support additional graphics processing units (GPUs) for enhanced image rendering capabilities.
In healthcare IT systems, it can serve as a server for managing patient records, electronic health records, and medical imaging data. The support for ECC memory ensures imaging data. The support for ECC memory ensures the integrity of patient data, and the advanced security features help protect sensitive medical information from cyber threats.
Video Surveillance and Security
In large-scale video surveillance systems, it can handle the processing and storage of video data from multiple cameras. The multi-core processor can perform real-time video analytics, such as object detection, facial recognition, and motion tracking. The motherboard's PCI Express 3.0 channels can support high-speed data transfer for video streaming and storage expansion, while the security features can protect the surveillance system from unauthorized access and data breaches.
Aerospace and Defense
In avionics systems, it can be used for flight control, navigation, and communication. The high processing power and reliability features make it suitable for handling the complex algorithms and real-time data processing required in aircraft systems. The support for ECC memory and advanced security features are crucial for ensuring the safety and security of aerospace applications.
In defense systems, it can be used for command and control centers, handling the communication and data processing for military operations. The motherboard's expandability allows for the integration of various sensors, communication modules, and other equipment required for defense applications.

Advantech 96MPXE-2.1-16M36's Attributes

Advantech 96MPXE-2.1-16M36's Datasheet

Advantech 96MPXE-2.1-16M36's Alternative Parts:

Processor: The Intel Xeon Silver 4216 can be an alternative to the Intel Xeon Silver 4116 used in 96MPXE - 2.1 - 16M361. Both belong to the Intel Xeon series and have similar architectures. The 4216 has a frequency of 2.1 GHz, 22 MB cache, and 16 cores, which is close to the 4116 in core count and frequency, and can provide similar processing power1.

Memory: If there is a need to upgrade or replace the memory, DDR4 - 2400 ECC memory modules from other reliable brands can be considered, as long as they meet the motherboard's memory specification requirements. For example, some memory modules from Kingston or Samsung that are compatible with the motherboard's memory slots and support ECC functionality can be used as alternatives.

Expansion Cards: Depending on the specific application requirements, different types of expansion cards can be used to replace or expand the functionality of the original device. For example, if more network interfaces are needed, a PCI - Express Ethernet expansion card can be selected; if additional storage interfaces are required, a SATA or NVMe expansion card can be considered. Well - known brands such as Intel and Broadcom offer a variety of expansion cards that are compatible with the 96MPXE - 2.1 - 16M36.

It should be noted that when choosing alternative parts, it is necessary to ensure their compatibility with the 96MPXE - 2.1 - 16M36 to avoid potential compatibility issues that could affect the normal operation of the system.

Advantech 96MPXE-2.1-16M36's Category-Microprocessors

Microprocessors, as the core of modern electronic devices, can be regarded as the "brain" of the digital era. It integrates key components such as arithmetic units and controllers. By processing data at high speed and executing instructions, it drives the operation of various devices like computers, smartphones, and smart home appliances. From simply handling basic computing tasks in the early days to supporting highly complex operations such as artificial intelligence and big data analysis nowadays, the performance of microprocessors has made remarkable leaps. Its manufacturing process has been continuously refined, and the number of transistors has increased significantly, bringing about higher computing speeds, lower power consumption, and stronger processing capabilities. It is widely applied in fields such as industrial control, healthcare, and aerospace.
Relying on advanced microprocessor technology, the Advantech 96MPXE-2.1-16M36 can give full play to the advantages of high-performance processors like the Intel Xeon Silver 4116. It performs excellently in multi-task processing, data calculation, and storage. With its outstanding compatibility, expandability, and stability, it provides reliable hardware support for complex application scenarios such as industrial automation and intelligent energy management, and serves as a powerful guarantee for promoting the digital and intelligent development of the industry.

96MPXE-2.1-16M36's Manufacturer-Advantech

Advantech has firmly established itself as a pioneer and a dominant force in the microprocessors domain, contributing significantly to technological advancements across multiple industries. The company excels in developing industrial - grade computing solutions that integrate state - of - the - art microprocessors. By leveraging high - performance microprocessors such as Intel Xeon series, Advantech products, like the 96MPXE-2.1-16M36, offer outstanding processing power, enabling seamless handling of complex multi - tasking and data - intensive operations. This is crucial for industrial automation, where real - time control and data analysis are required. Advantech's commitment to innovation is evident in its continuous research and development efforts. It focuses on optimizing the performance, reliability, and energy efficiency of microprocessor - based systems. Its products are designed to withstand harsh industrial environments, with enhanced durability and advanced security features. This has led to wide adoption in sectors such as aerospace, healthcare, and smart energy management. In addition, Advantech promotes the development of open - source and standardized architectures, facilitating the integration of microprocessors into various systems. This not only accelerates technological progress but also helps to build a more interconnected and intelligent industrial ecosystem. Overall, Advantech's achievements in the microprocessors field have set industry benchmarks and driven digital transformation across numerous sectors.

96MPXE-2.2-13M36 vs 96MPXE-2.1-16M36

Part Number	96MPXE-2.2-13M36 +BOM	96MPXE-2.1-16M36 +BOM
Category	Embedded - Microprocessors	Embedded - Microprocessors
Manufacturer	Advantech Corp	Advantech Corp
Description	XEON 2.2G 13.75M 3647P 10C 4114T	XEON 2.1G 16.5M 3647P 12C 4116 7
Package	Bulk	Bulk
Series	Skylake	Skylake
Operating Temperature	-	-
Package / Case	3647-LGA Module	3647-LGA Module
Supplier Device Package	3647-FCLGA (76x56.5)	3647-FCLGA (76x56.5)
Speed	2.2GHz	2.1GHz
Voltage - I/O	-	-
Core Processor	Xeon Silver 4114T	Xeon Silver 4116
Number of Cores/Bus Width	10 Core, 64-Bit	12 Core, 64-Bit
RAM Controllers	DDR4	DDR4
Graphics Acceleration	No	No
Display & Interface Controllers	-	-
Ethernet	-	-
USB	-	-
Security Features	-	-
Co-Processors/DSP	-	-
SATA	-	-
