Gates and Inverters(16927)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Operating Temperature | Mounting Type | Package / Case | Features | Base Product Number | Number of Circuits | Voltage - Supply | Supplier Device Package | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | REACH Status | Other Names | ECCN | HTSUS | Standard Package | Logic Type | Current - Output High, Low | Current - Quiescent (Max) | Number of Inputs | Max Propagation Delay @ V, Max CL | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
74V1T04STR | - |  |
8784 | 0.00000000 | STMicroelectronics | 74V | Tape & Reel (TR) | Obsolete | -55°C ~ 125°C | Surface Mount | SC-74A, SOT-753 | - | 74V1T04 | 1 | 4.5V ~ 5.5V | SOT-23-5 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 3,000 | Inverter | 8mA, 8mA | 1 µA | 1 | 7.7ns @ 5V, 50pF | 0.8V | 2V | ||
 |
74AUP1G02GS,132 | 0.4700 | |
5 | 0.00000000 | Nexperia USA Inc. | 74AUP | Tape & Reel (TR) | Active | -40°C ~ 125°C | Surface Mount | 6-XFDFN | - | 74AUP1G02 | 1 | 0.8V ~ 3.6V | 6-XSON, SOT1202 (1x1) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 5,000 | NOR Gate | 4mA, 4mA | 500 nA | 2 | 6.4ns @ 3.3V, 30pF | 0.7V ~ 0.9V | 1.6V ~ 2V | ||
 |
CD74HC86MG4 | - | |
9979 | 0.00000000 | Texas Instruments | 74HC | Tube | Discontinued at SIC | -55°C ~ 125°C | Surface Mount | 14-SOIC (0.154", 3.90mm Width) | - | 74HC86 | 4 | 2V ~ 6V | 14-SOIC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 50 | XOR (Exclusive OR) | 5.2mA, 5.2mA | 2 µA | 2 | 20ns @ 6V, 50pF | 0.5V ~ 1.8V | 1.5V ~ 4.2V | ||
 |
TC7W04FU(TE12L) | - | |
8653 | 0.00000000 | Toshiba Semiconductor and Storage | 7W | Digi-Reel® | Obsolete | -40°C ~ 85°C | Surface Mount | 8-TSSOP, 8-MSOP (0.110", 2.80mm Width) | - | 7W04 | 3 | 2V ~ 6V | 8-SSOP | download | RoHS non-compliant | 1 (Unlimited) | EAR99 | 8542.39.0001 | 3,000 | Inverter | 5.2mA, 5.2mA | 1 µA | 1 | 13ns @ 6V, 50pF | 0.5V ~ 1.8V | 1.5V ~ 4.2V | |||
 |
SN74LV11APWTG4 | - | |
7153 | 0.00000000 | Texas Instruments | 74LV | Tape & Reel (TR) | Obsolete | -40°C ~ 85°C | Surface Mount | 14-TSSOP (0.173", 4.40mm Width) | - | 74LV11 | 3 | 2V ~ 5.5V | 14-TSSOP | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 1,000 | AND Gate | 12mA, 12mA | 20 µA | 3 | 7.9ns @ 5V, 50pF | 0.5V | 1.5V | ||
 |
74LVC1G00FX4-7 | 0.1167 | |
3046 | 0.00000000 | Diodes Incorporated | 74LVC | Tape & Reel (TR) | Active | -40°C ~ 125°C (TA) | Surface Mount | 6-XFDFN | - | 74LVC1G00 | 1 | 1.65V ~ 5.5V | X2-DFN1409-6 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 5,000 | NAND Gate | 32mA, 32mA | 200 µA | 2 | 5.5ns @ 5V, 50pF | 0.7V ~ 0.8V | 1.7V ~ 2V | ||
 |
74LVC1G02GW-Q100125 | - | |
4738 | 0.00000000 | NXP USA Inc. | * | Bulk | Active | 74LVC1G02 | download | Not applicable | 3 (168 Hours) | Vendor Undefined | EAR99 | 8542.39.0001 | 1 | ||||||||||||||||
|
SN74LVC32APWRG3 | 0.5300 | |
55 | 0.00000000 | Texas Instruments | 74LVC | Tape & Reel (TR) | Active | -40°C ~ 125°C | Surface Mount | 14-TSSOP (0.173", 4.40mm Width) | - | 74LVC32 | 4 | 1.65V ~ 3.6V | 14-TSSOP | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 2,000 | OR Gate | 24mA, 24mA | 1 µA | 2 | 3.6ns @ 3.3V, 50pF | 0.7V ~ 0.8V | 1.7V ~ 2V | ||
 |
CD74AC05E | 0.7500 | |
806 | 0.00000000 | Texas Instruments | 74AC | Tube | Active | -55°C ~ 125°C | Through Hole | 14-DIP (0.300", 7.62mm) | Open Drain | 74AC05 | 6 | 1.5V ~ 5.5V | 14-PDIP | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 25 | Inverter | -, 24mA | 4 µA | 1 | 8.2ns @ 5V, 50pF | 0.3V ~ 1.65V | 1.2V ~ 3.85V | ||
|
74LVC1GU04GS,132 | 0.1103 | |
5203 | 0.00000000 | Nexperia USA Inc. | 74LVC | Tape & Reel (TR) | Active | -40°C ~ 125°C | Surface Mount | 6-XFDFN | - | 74LVC1GU04 | 1 | 1.65V ~ 5.5V | 6-XSON, SOT1202 (1x1) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 5,000 | Inverter | 32mA, 32mA | 4 µA | 1 | 3ns @ 5V, 50pF | - | - | ||
|
SN74LVC10ADG4 | - | |
5572 | 0.00000000 | Texas Instruments | 74LVC | Tube | Discontinued at SIC | -40°C ~ 125°C | Surface Mount | 14-SOIC (0.154", 3.90mm Width) | - | 74LVC10 | 3 | 1.65V ~ 3.6V | 14-SOIC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 50 | NAND Gate | 24mA, 24mA | 1 µA | 3 | 4.7ns @ 3.3V, 50pF | 0.7V ~ 0.8V | 1.7V ~ 2V | ||
|
SN74LS04DR | 0.7900 | |
12 | 0.00000000 | Texas Instruments | 74LS | Tape & Reel (TR) | Active | 0°C ~ 70°C | Surface Mount | 14-SOIC (0.154", 3.90mm Width) | - | 74LS04 | 6 | 4.75V ~ 5.25V | 14-SOIC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 2,500 | Inverter | 400µA, 8mA | 1 | 15ns @ 5V, 15pF | 0.8V | 2V | |||
 |
NLVHCT14ADR2G | 0.1618 | |
3650 | 0.00000000 | onsemi | Automotive, AEC-Q100, 74HCT | Tape & Reel (TR) | Active | -55°C ~ 125°C | Surface Mount | 14-SOIC (0.154", 3.90mm Width) | Schmitt Trigger | NLVHCT14 | 6 | 4.5V ~ 5.5V | 14-SOIC | - | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 2,500 | Inverter | 4mA, 4mA | 1 µA | 1 | 32ns @ 5V, 50pF | 0.1V ~ 0.26V | 3.98V ~ 5.4V | ||
 |
74LVT08D,112 | 1.2700 | |
36 | 0.00000000 | Nexperia USA Inc. | 74LVT | Tube | Obsolete | -40°C ~ 85°C | Surface Mount | 14-SOIC (0.154", 3.90mm Width) | - | 74LVT08 | 4 | 2.7V ~ 3.6V | 14-SO | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 57 | AND Gate | 20mA, 32mA | 2 | 3.4ns @ 3.3V, 50pF | 0.8V | 2V | |||
 |
NC7SV32FHX | - | |
5034 | 0.00000000 | onsemi | 7SV | Tape & Reel (TR) | Obsolete | -40°C ~ 85°C | Surface Mount | 6-UFDFN | - | 7SV32 | 1 | 0.9V ~ 3.6V | 6-MicroPak2™ | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 5,000 | OR Gate | 24mA, 24mA | 900 nA | 2 | 3.3ns @ 3V, 30pF | 0.7V ~ 0.8V | 1.6V ~ 2V | ||
|
SN74HCT04DR | 0.4000 | |
12 | 0.00000000 | Texas Instruments | 74HCT | Tape & Reel (TR) | Active | -40°C ~ 85°C | Surface Mount | 14-SOIC (0.154", 3.90mm Width) | - | 74HCT04 | 6 | 4.5V ~ 5.5V | 14-SOIC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 2,500 | Inverter | 4mA, 4mA | 2 µA | 1 | 18ns @ 5.5V, 50pF | 0.8V | 2V | ||
 |
JM54AC86SDA-RH | 319.5200 | |
109 | 0.00000000 | National Semiconductor | 54AC | Bulk | Active | -55°C ~ 125°C | Surface Mount | 14-CFlatPack | - | 4 | 2V ~ 6V | 14-CFP | download | EAR99 | 8542.39.0001 | 1 | XOR (Exclusive OR) | 24mA, 24mA | 40 µA | 2 | 10ns @ 5V, 50pF | 0.9V ~ 1.65V | 2.1V ~ 3.85V | ||||||
 |
SN74LVC1G04YEPR | - | |
3762 | 0.00000000 | Texas Instruments | 74LVC | Tape & Reel (TR) | Obsolete | -40°C ~ 85°C | Surface Mount | 5-XFBGA, DSBGA | - | 74LVC1G04 | 1 | 1.65V ~ 5.5V | 5-DSBGA (1.4x0.9) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 3,000 | Inverter | 32mA, 32mA | 10 µA | 1 | 3.7ns @ 5V, 50pF | 0.7V ~ 0.8V | 1.7V ~ 2V | ||
|
SN74HC21DRE4 | - | |
8548 | 0.00000000 | Texas Instruments | 74HC | Tape & Reel (TR) | Obsolete | -40°C ~ 85°C | Surface Mount | 14-SOIC (0.154", 3.90mm Width) | - | 74HC21 | 2 | 2V ~ 6V | 14-SOIC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 2,500 | AND Gate | 5.2mA, 5.2mA | 2 µA | 4 | 19ns @ 6V, 50pF | 0.5V ~ 1.8V | 1.5V ~ 4.2V | ||
 |
DM74ALS02MX | - | |
8316 | 0.00000000 | onsemi | 74ALS | Tape & Reel (TR) | Obsolete | 0°C ~ 70°C | Surface Mount | 14-SOIC (0.154", 3.90mm Width) | - | 74ALS02 | 4 | 4.5V ~ 5.5V | 14-SOIC | download | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 2,500 | NOR Gate | 400µA, 8mA | 2 | 12ns @ 5V, 50pF | 0.8V | 2V | ||||
|
JM54AC10S2A-RH | 451.9900 | |
256 | 0.00000000 | National Semiconductor | 54AC | Bulk | Active | -55°C ~ 125°C | Surface Mount | 20-CLCC | - | 54AC10 | 3 | 2V ~ 6V | 20-LCCC (8.89x8.89) | download | EAR99 | 8542.39.0001 | 1 | NAND Gate | 24mA, 24mA | 40 µA | 3 | 7ns @ 5V, 50pF | 0.9V ~ 1.65V | 2.1V ~ 3.85V | |||||
 |
SN74HC7266N | 0.6600 | |
1 | 0.00000000 | Texas Instruments | 74HC | Bulk | Active | -55°C ~ 125°C | Through Hole | 14-DIP (0.300", 7.62mm) | - | 74HC7266 | 4 | 2V ~ 6V | 14-PDIP | download | RoHS non-compliant | 3 (168 Hours) | REACH Affected | EAR99 | 8542.39.0001 | 1 | XNOR (Exclusive NOR) | 5.2mA, 5.2mA | 2 µA | 2 | 20ns @ 6V, 50pF | 0.3V ~ 1.2V | 1.5V ~ 4.2V | ||
 |
DM74ALS32SJX | - | |
1882 | 0.00000000 | onsemi | 74ALS | Tape & Reel (TR) | Obsolete | 0°C ~ 70°C | Surface Mount | 14-SOIC (0.209", 5.30mm Width) | - | 74ALS32 | 4 | 4.5V ~ 5.5V | 14-SOP | download | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 2,000 | OR Gate | 400µA, 8mA | 2 | 14ns @ 5V, 50pF | 0.8V | 2V | ||||
 |
SN74AUC2G04YEPR | - | |
2071 | 0.00000000 | Texas Instruments | 74AUC | Tape & Reel (TR) | Obsolete | -40°C ~ 85°C | Surface Mount | 6-XFBGA, DSBGA | - | 74AUC2G04 | 2 | 0.8V ~ 2.7V | 6-DSBGA | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 3,000 | Inverter | 9mA, 9mA | 10 µA | 1 | 1.5ns @ 2.5V, 30pF | 0V ~ 0.7V | 1.7V | ||
 |
74LVC1G00GM,132 | 0.1040 | |
5988 | 0.00000000 | Nexperia USA Inc. | 74LVC | Tape & Reel (TR) | Active | -40°C ~ 125°C | Surface Mount | 6-XFDFN | - | 74LVC1G00 | 1 | 1.65V ~ 5.5V | 6-XSON, SOT886 (1.45x1) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 5,000 | NAND Gate | 32mA, 32mA | 4 µA | 2 | 4ns @ 5V, 50pF | 0.7V ~ 0.8V | 1.7V ~ 2V | ||
|
74HC05D-Q100,118 | 0.5500 | |
5718 | 0.00000000 | Nexperia USA Inc. | Automotive, AEC-Q100, 74HC | Tape & Reel (TR) | Active | -40°C ~ 125°C | Surface Mount | 14-SOIC (0.154", 3.90mm Width) | Open Drain | 74HC05 | 6 | 2V ~ 6V | 14-SO | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 2,500 | Inverter | -, 5.2mA | 2 µA | 1 | 13ns @ 6V, 50pF | 0.5V ~ 1.8V | 1.5V ~ 4.2V | ||
|
NLV74HCU04ADTR2G | - | |
5489 | 0.00000000 | Rochester Electronics, LLC | 74HCU | Bulk | Active | -55°C ~ 125°C | Surface Mount | 14-TSSOP (0.173", 4.40mm Width) | - | 6 | 2V ~ 6V | 14-TSSOP | - | RoHS non-compliant | Vendor Undefined | 2156-NLV74HCU04ADTR2G-2156 | 1 | Inverter | 5.2mA, 5.2mA | 1 µA | 6 | 12ns @ 6V, 50pF | 0.3V ~ 1.1V | 1.7V ~ 4.8V | |||||
 |
74VHC14YTTR | 0.4971 | |
8354 | 0.00000000 | STMicroelectronics | Automotive, AEC-Q100, 74VHC | Tape & Reel (TR) | Active | -40°C ~ 125°C | Surface Mount | 14-TSSOP (0.173", 4.40mm Width) | Schmitt Trigger | 74VHC14 | 6 | 2V ~ 5.5V | 14-TSSOP | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 2,500 | Inverter | 8mA, 8mA | 2 µA | 1 | 10.6ns @ 5V, 50pF | 0.9V ~ 1.65V | 2.2V ~ 3.85V | ||
 |
74LVC1G08GX,125 | 0.4800 | |
9 | 0.00000000 | Nexperia USA Inc. | 74LVC | Tape & Reel (TR) | Active | -40°C ~ 125°C (TA) | Surface Mount | 4-XFDFN Exposed Pad | - | 74LVC1G08 | 1 | 1.65V ~ 5.5V | 5-X2SON (0.80x0.80) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 10,000 | AND Gate | 32mA, 32mA | 4 µA | 2 | 4ns @ 5V, 50pF | 0.7V ~ 0.8V | 1.7V ~ 2V | ||
|
SN74LV05APWT | 1.0700 | |
2900 | 0.00000000 | Texas Instruments | 74LV | Tape & Reel (TR) | Active | -40°C ~ 85°C | Surface Mount | 14-TSSOP (0.173", 4.40mm Width) | Open Drain | 74LV05 | 6 | 2V ~ 5.5V | 14-TSSOP | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8542.39.0001 | 250 | Inverter | -, 12mA | 20 µA | 1 | 7.5ns @ 5V, 50pF | 0.5V | 1.5V |
