Switches(3201)

Image Product Number Pricing(USD) Quantity ECAD Quantity Available Weight(Kg) Mfr Series Package Product Status Operating Temperature Mounting Type Features Base Product Number Ingress Protection Termination Style DataSheet RoHS Status Moisture Sensitivity Level (MSL) REACH Status Other Names ECCN HTSUS Standard Package Circuit Current Rating (Amps) Voltage Rating - AC Voltage Rating - DC Actuator Type Switch Function Mechanical Life Electrical Life Operating Force Release Force Operating Position Pretravel Differential Travel Overtravel
ABS1412403 Panasonic Electric Works ABS1412403 2.8100
RFQ
 ECAD 164 0.00000000 Panasonic Electric Works ABS Bulk Obsolete -40°C ~ 85°C Chassis Mount - ABS141 IP50 - Dust Protected Solder Lug download RoHS Compliant 1 (Unlimited) 255-5819 EAR99 8536.50.9055 100 SPDT 2A (AC/DC) 125 V 30 V Lever, Straight On-Mom 5,000,000 Cycles 50,000 Cycles 35gf 3.059gf 0.345" (8.8mm) 0.110" (2.8mm) 0.031" (0.8mm) 0.047" (1.2mm)
ABS1110509 Panasonic Electric Works ABS1110509 2.1270
RFQ
 ECAD 3485 0.00000000 Panasonic Electric Works ABS Bulk Active -40°C ~ 85°C Chassis Mount - ABS111 IP50 - Dust Protected Quick Connect - 0.110" (2.8mm) download RoHS Compliant 1 (Unlimited) EAR99 8536.50.7000 100 SPDT 2A (AC/DC) 125 V 30 V Round (Pin Plunger) On-Mom 5,000,000 Cycles 50,000 Cycles 150gf 20gf 0.330" (8.4mm) 0.024" (0.6mm) 0.004" (0.1mm) 0.015" (0.4mm)
AM50643D33-A Panasonic Electric Works AM50643D33-A -
RFQ
 ECAD 7004 0.00000000 Panasonic Electric Works AM5 Bulk Obsolete -25°C ~ 105°C Chassis Mount - AM50643 - Quick Connect - 0.250" (6.3mm) download 1 (Unlimited) REACH Unaffected -AM50643D33 EAR99 8536.50.7000 50 SPDT 6A (AC), 500mA (DC) 125 V 125 V Lever, Straight On-Mom 10,000,000 Cycles 100,000 Cycles 15gf 2.500gf 0.602" (15.3mm) 0.296" (7.5mm) 0.080" (2.0mm) 0.087" (2.2mm)
ABS5512349 Panasonic Electric Works ABS5512349 3.2569
RFQ
 ECAD 3382 0.00000000 Panasonic Electric Works ABS Bulk Active -40°C ~ 85°C Through Hole, Right Angle Actuator Mounted Left Side ABS551 IP50 - Dust Protected PC Pin download RoHS Compliant 1 (Unlimited) EAR99 8536.50.9055 100 SPDT 100mA (DC) 30 V Lever, Straight On-Mom 5,000,000 Cycles 200,000 Cycles 28gf 1.734gf 0.345" (8.8mm) 0.110" (2.8mm) 0.031" (0.8mm) 0.047" (1.2mm)
AV63421264 Panasonic Electric Works AV63421264 4.4016
RFQ
 ECAD 6143 0.00000000 Panasonic Electric Works AV6 Bulk Active -25°C ~ 85°C Chassis Mount - AV634 IP40 Connector download RoHS Compliant 1 (Unlimited) EAR99 8536.50.7000 100 SPST-NO 100mA (DC) 30 V Lever, Simulated Roller Off-Mom 500,000 Cycles 200,000 Cycles 36gf 3.059gf 0.445" (11.3mm) 0.055" (1.4mm) 0.025" (0.6mm) 0.026" (0.7mm)
AH72554569-A Panasonic Electric Works AH72554569-A -
RFQ
 ECAD 9227 0.00000000 Panasonic Electric Works AH7 Bulk Obsolete -25°C ~ 80°C Chassis Mount - AH725 - Solder, Quick Connect - 0.187" (4.7mm) download 1 (Unlimited) REACH Unaffected -AH72554569 EAR99 8536.50.7000 50 SPST-NC 10A (AC), 600mA (DC) 250 V 125 V Lever, Roller On-Mom 10,000,000 Cycles 100,000 Cycles 110gf 20gf 0.815" (20.7mm) 0.063" (1.6mm) 0.020" (0.5mm) 0.030" (0.76mm)
AH71517559-A Panasonic Electric Works AH71517559-A -
RFQ
 ECAD 4786 0.00000000 Panasonic Electric Works AH7 Bulk Obsolete -25°C ~ 80°C Chassis Mount - AH715 - Solder, Quick Connect - 0.187" (4.7mm) download 1 (Unlimited) REACH Unaffected -AH71517559 EAR99 8536.50.9040 50 SPDT 15A (AC), 600mA (DC) 250 V 125 V Lever, Straight On-Mom 10,000,000 Cycles 100,000 Cycles 420gf 80gf 0.602" (15.3mm) 0.063" (1.6mm) 0.020" (0.5mm) 0.030" (0.76mm)
AH71504609-A Panasonic Electric Works AH71504609-A -
RFQ
 ECAD 3764 0.00000000 Panasonic Electric Works AH7 Bulk Obsolete -25°C ~ 80°C Chassis Mount - AH715 - Solder, Quick Connect - 0.187" (4.7mm) download 1 (Unlimited) REACH Unaffected -AH71504609 EAR99 8536.50.7000 100 SPDT 10A (AC), 600mA (DC) 250 V 125 V Round (Pin Plunger) On-Mom 10,000,000 Cycles 100,000 Cycles 100gf 25gf 0.579" (14.7mm) 0.063" (1.6mm) 0.016" (0.4mm) 0.030" (0.76mm)
AV4044 Panasonic Electric Works AV4044 1.9400
RFQ
 ECAD 753 0.00000000 Panasonic Electric Works AV4 Bulk Active -25°C ~ 80°C Chassis Mount - AV404 - Solder Lug download RoHS Compliant 1 (Unlimited) EAR99 8536.50.7000 500 SPDT 500mA (DC) 30 V Lever, Simulated Roller On-Mom 300,000 Cycles 20,000 Cycles 29gf - 0.264" (6.7mm) 0.087" (2.2mm) 0.027" (0.7mm) 0.011" (0.3mm)
ABV1214519 Panasonic Electric Works ABV1214519 5.0306
RFQ
 ECAD 8258 0.00000000 Panasonic Electric Works ABV Bulk Active -40°C ~ 85°C Chassis Mount - ABV121 IP50 - Dust Protected Solder, Quick Connect - 0.187" (4.7mm) download RoHS Compliant 1 (Unlimited) EAR99 8536.50.9055 50 SPDT 3A (AC) 250 V Lever, Simulated Roller On-Mom 5,000,000 Cycles 100,000 Cycles 120gf 13gf 0.730" (18.5mm) 0.125" (3.2mm) 0.047" (1.2mm) 0.047" (1.2mm)
AVM3235119 Panasonic Electric Works AVM3235119 1.5862
RFQ
 ECAD 1824 0.00000000 Panasonic Electric Works AVM3 Bulk Active -25°C ~ 85°C Chassis Mount - AVM323 - Solder Lug download RoHS Compliant 1 (Unlimited) EAR99 8536.50.7000 500 SPDT 5A (AC/DC) 125 V 30 V Lever, Straight On-Mom 10,000,000 Cycles 50,000 Cycles 45gf 3.059gf 0.345" (8.8mm) 0.138" (3.5mm) 0.040" (1.0mm) 0.062" (1.6mm)
AM51651D63N-A Panasonic Electric Works AM51651D63N-A -
RFQ
 ECAD 8244 0.00000000 Panasonic Electric Works AM5 Bulk Obsolete -25°C ~ 105°C Chassis Mount Cadmium Free AM51651 - Quick Connect - 0.250" (6.3mm) download 1 (Unlimited) EAR99 8536.50.9040 50 SPST-NC 16A (AC), 600mA (DC) 125 V 125 V Lever, Straight On-Mom 10,000,000 Cycles 100,000 Cycles 320gf 60gf 0.602" (15.3mm) 0.063" (1.6mm) 0.020" (0.5mm) 0.035" (0.9mm)
AGX726 Panasonic Electric Works AGX726 -
RFQ
 ECAD 9102 0.00000000 Panasonic Electric Works AGX Bulk Obsolete -25°C ~ 85°C Panel Mount, Snap-In - IP40 Quick Connect - 0.110"/0.250" download 1 (Unlimited) REACH Unaffected EAR99 8536.50.9040 100 3PST-NO 16A (AC) 125 V Round (Pin Plunger) Off-Mom 1,000,000 Cycles 100,000 Cycles 600gf - 0.276" (7.0mm) - - 0.158" (4.0mm)
AH18649-A Panasonic Electric Works AH18649-A 1.5940
RFQ
 ECAD 3192 0.00000000 Panasonic Electric Works AH1 Tube Active -25°C ~ 85°C Through Hole, Right Angle Actuator Mounted Left Side AH18649 - PC Pin download RoHS Compliant 1 (Unlimited) -AH18649 EAR99 8536.50.7000 50 SPDT 3A (AC), 2A (DC) 125 V 30 V Lever, Simulated Roller On-Mom 500,000 Cycles 30,000 Cycles 55gf 4.079gf 0.374" (9.5mm) 0.083" (2.1mm) 0.020" (0.5mm) 0.020" (0.5mm)
AVL3855613 Panasonic Electric Works AVL3855613 1.4332
RFQ
 ECAD 8940 0.00000000 Panasonic Electric Works AVL3 Bulk Active -25°C ~ 85°C Chassis Mount - AVL385 - Quick Connect - 0.110" (2.8mm) download RoHS Compliant 1 (Unlimited) -AVL3855613-ND EAR99 8536.50.7000 100 SPDT 100mA (AC/DC) 125 V 30 V Lever, Roller On-Mom 10,000,000 Cycles 50,000 Cycles 60gf 4.079gf 0.571" (14.5mm) 0.100" (2.5mm) 0.020" (0.5mm) 0.030" (0.76mm)
AVM3415613 Panasonic Electric Works AVM3415613 1.3408
RFQ
 ECAD 3590 0.00000000 Panasonic Electric Works AVM3 Bulk Active -25°C ~ 85°C Through Hole - - PC Pin - 255-AVM3415613 100 SPDT 100mA (AC/DC) 125 V 30 V Lever, Straight On-Mom 10,000,000 Cycles 200,000 Cycles 60gf 4.079gf 0.346" (8.80mm) 0.100" (2.5mm) 0.020" (0.5mm) 0.031" (0.8mm)
AM50043D53-A Panasonic Electric Works AM50043D53-A -
RFQ
 ECAD 1828 0.00000000 Panasonic Electric Works AM5 Bulk Obsolete -25°C ~ 105°C Chassis Mount - AM50043 - Quick Connect - 0.250" (6.3mm) download 1 (Unlimited) EAR99 8536.50.7000 50 SPDT 100mA (AC/DC) 125 V 30 V Lever, Straight On-Mom 10,000,000 Cycles 100,000 Cycles 60gf 10gf 0.602" (15.3mm) 0.296" (7.5mm) 0.080" (2.0mm) 0.087" (2.2mm)
AM50024A33-A Panasonic Electric Works AM50024A33-A -
RFQ
 ECAD 1385 0.00000000 Panasonic Electric Works AM5 Bulk Obsolete -25°C ~ 105°C Chassis Mount - AM50024 - Solder, Quick Connect - 0.187" (4.7mm) download 1 (Unlimited) EAR99 8536.50.7000 50 SPST-NC 100mA (AC/DC) 125 V 30 V Lever, Simulated Roller On-Mom 10,000,000 Cycles 100,000 Cycles 30gf 5.099gf 0.730" (18.5mm) 0.125" (3.2mm) 0.040" (1.0mm) 0.055" (1.4mm)
ASQ10338 Panasonic Electric Works ASQ10338 8.0300
RFQ
 ECAD 3801 0.00000000 Panasonic Electric Works ASQ1 Bulk Active -40°C ~ 85°C Chassis Mount - ASQ103 IP67 - Dust Tight, Waterproof Wire Leads download RoHS Compliant 1 (Unlimited) EAR99 8536.50.7000 1,000 SPST-NO 100mA (DC) 30 V Lever, Simulated Roller Off-Mom - 200,000 Cycles 153gf - 0.472" (12.0mm) - - 0.110" (2.8mm)
AV442461 Panasonic Electric Works AV442461 2.4300
RFQ
 ECAD 1 0.00000000 Panasonic Electric Works AV4 Bulk Active -25°C ~ 80°C Through Hole - AV442 - PC Pin download RoHS Compliant 1 (Unlimited) EAR99 8536.50.7000 100 SPDT 100mA (DC) 30 V Lever, Straight On-Mom 300,000 Cycles 200,000 Cycles 25gf - 0.228" (5.8mm) 0.094" (2.4mm) 0.027" (0.7mm) 0.015" (0.4mm)
AM50663C33-A Panasonic Electric Works AM50663C33-A -
RFQ
 ECAD 9720 0.00000000 Panasonic Electric Works AM5 Bulk Obsolete -25°C ~ 105°C Chassis Mount - AM50663 - Quick Connect - 0.187" (4.7mm) download 1 (Unlimited) EAR99 8536.50.7000 50 SPST-NO 6A (AC), 500mA (DC) 125 V 125 V Lever, Straight Off-Mom 10,000,000 Cycles 100,000 Cycles 15gf 2.500gf 0.602" (15.3mm) 0.296" (7.5mm) 0.080" (2.0mm) 0.087" (2.2mm)
AM51112A43N-A Panasonic Electric Works AM51112A43N-A -
RFQ
 ECAD 9023 0.00000000 Panasonic Electric Works AM5 Bulk Obsolete -25°C ~ 105°C Chassis Mount Cadmium Free AM51112 - Solder, Quick Connect - 0.187" (4.7mm) download 1 (Unlimited) EAR99 8536.50.7000 50 SPDT 11A (AC), 600mA (DC) 125 V 125 V Lever, Straight On-Mom 10,000,000 Cycles 100,000 Cycles 60gf 10gf 0.602" (15.3mm) 0.125" (3.2mm) 0.040" (1.0mm) 0.055" (1.4mm)
AVT384461 Panasonic Electric Works AVT384461 1.1817
RFQ
 ECAD 4104 0.00000000 Panasonic Electric Works AVT3 Bulk Active -25°C ~ 85°C Chassis Mount - IP40 Quick Connect - 0.110" (2.8mm) - 255-AVT384461 100 SPDT 100mA (AC/DC) 125 V 30 V Lever, Simulated Roller On-Mom 500,000 Cycles 200,000 Cycles 35gf 2.957gf 0.459" (11.65mm) 0.110" (2.8mm) 0.031" (0.80mm) 0.047" (1.20mm)
AH74563609-A Panasonic Electric Works AH74563609-A -
RFQ
 ECAD 6672 0.00000000 Panasonic Electric Works AH7 Bulk Obsolete -25°C ~ 80°C Chassis Mount - AH745 - Solder, Quick Connect - 0.187" (4.7mm) download 1 (Unlimited) REACH Unaffected -AH74563609 EAR99 8536.50.9055 50 SPDT 5A (AC), 500mA (DC) 250 V 125 V Lever, Roller On-Mom 10,000,000 Cycles 100,000 Cycles 30gf 5.099gf 0.815" (20.7mm) 0.125" (3.2mm) 0.047" (1.2mm) 0.047" (1.2mm)
AV1185F Panasonic Electric Works AV1185F -
RFQ
 ECAD 3733 0.00000000 Panasonic Electric Works - Bulk Obsolete AV118 - RoHS Compliant 1 (Unlimited) 255-AV1185F OBSOLETE 1
ABJ262L70 Panasonic Electric Works ABJ262L70 5.2736
RFQ
 ECAD 2954 0.00000000 Panasonic Electric Works ABJ Bulk Active -40°C ~ 85°C Chassis Mount - ABJ262 IP67 - Dust Tight, Waterproof Wire Leads download RoHS Compliant 1 (Unlimited) -ABJ262L70-ND EAR99 8536.50.7000 50 SPST-NC 1A (AC/DC) 125 V 30 V Side Plunger On-Mom 500,000 Cycles 30,000 Cycles 250gf 20gf 0.098" (2.5mm) - 0.020" (0.5mm) 0.079" (2.0mm)
AM50031D53-A Panasonic Electric Works AM50031D53-A -
RFQ
 ECAD 5651 0.00000000 Panasonic Electric Works AM5 Bulk Obsolete -25°C ~ 105°C Chassis Mount - AM50031 - Quick Connect - 0.250" (6.3mm) download 1 (Unlimited) EAR99 8536.50.7000 50 SPST-NO 100mA (AC/DC) 125 V 30 V Lever, Straight Off-Mom 10,000,000 Cycles 100,000 Cycles 220gf 40gf 0.602" (15.3mm) 0.063" (1.6mm) 0.020" (0.5mm) 0.035" (0.9mm)
ABV1210513 Panasonic Electric Works ABV1210513 4.0800
RFQ
 ECAD 159 0.00000000 Panasonic Electric Works ABV Bulk Active -40°C ~ 85°C Chassis Mount - ABV121 IP50 - Dust Protected Solder, Quick Connect - 0.187" (4.7mm) download RoHS Compliant 1 (Unlimited) EAR99 8536.50.7000 50 SPDT 3A (AC) 250 V Round (Pin Plunger) On-Mom 5,000,000 Cycles 100,000 Cycles 200gf 40gf 0.579" (14.7mm) 0.063" (1.6mm) 0.016" (0.4mm) 0.030" (0.76mm)
AV355261 Panasonic Electric Works AV355261 1.6454
RFQ
 ECAD 1423 0.00000000 Panasonic Electric Works AV3 Bulk Active -25°C ~ 85°C Through Hole - - PC Pin - 255-AV355261 100 SPDT 100mA (AC/DC) 125 V 30 V Lever, Roller On-Mom 500,000 Cycles 200,000 Cycles 20gf 1.734gf 0.571" (14.50mm) 0.100" (2.5mm) 0.020" (0.5mm) 0.031" (0.8mm)
ABJ1412409 Panasonic Electric Works ABJ1412409 -
RFQ
 ECAD 9784 0.00000000 Panasonic Electric Works ABJ Bulk Obsolete -40°C ~ 85°C Chassis Mount - ABJ141 IP50 - Dust Protected Solder Lug download 1 (Unlimited) EAR99 8536.50.7000 100 SPDT 1A (AC/DC) 125 V 30 V Lever, Straight On-Mom 1,000,000 Cycles 6,000 Cycles 40gf 3.059gf 0.268" (6.8mm) 0.120" (3.0mm) 0.020" (0.5mm) 0.020" (0.5mm)
