In the domain of precision voltage comparators, the TS374IDT is a remarkable choice known for its reliability and efficiency. With four independent comparators, it can operate with either single or dual supplies, offering great versatility across numerous applications. These differential comparators are manufactured via STMicroelectronics' silicon lin MOS process, which guarantees an excellent consumption - speed ratio. Whether you require a low - consumption option or a component for high - voltage inverter power boards, the TS374IDT is bound to surpass your anticipations.

STMicroelectronics TS374IDT’s Features

Wide single supply range or dual supplies 3v to 16v or ±1.5v to ±8v
Very low supply current: 0.1ma/comp independent of supply voltage
Extremely low input bias current : 1pa typ
Extremely low input offset currents : 1pa typ
Low input offset voltage
Input common - mode voltage range includes gnd
Low output saturation voltage 150mv typ
Output compatible with ttl, mos and cmos
High input impedance : 10¹²ω typ
Fast response time : 200ns typ for ttl - level input step
